Shenzhen Hawell Advanced Technology Co., Ltd.
China Manufacturer with main products: CCTV Product, DVR, Camera |
Array LED waterproof camera
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
1 1/3” SONY Super HAD II CCD, Color definition 420/540 TV line. Build-in dot-matrix IR LED, night-vision distance up to 50M. Build-in CS HD huge-light transmission IR Lens (16mm/F1.2)
2. The 3rd generation high-power dot-matrix array LED not only owns the 2nd generation’s advantage of small volume, good heat-dissipation, and long life time, but also solves the 2nd generation’s shortage of brightness caused by polarized light. This new generation IR LED component owns the advantage of 1st and 2nd generation, and totally avoids their shortage.
3. High brightness: single LED Array’s output is about 1W-20W, and its brightness is hundreds times of ordinary single LED’s 5-15mW.
4. High efficiency: LED Array electro-optical conversion efficiency has promoted 25% more than ordinary IR LED.
5. LED Array is high integrated chipset, so its volume is smaller than other IR products at the same brightness.
6. LED Array’s life time is 10000H, about 9 times of ordinary LED life time.
7. LED Array’s illuminant is a lighting-emitting surface which owns 10-120 degree (adjustable). It solves Flashlight effect that ordinary LED makes night vision screen’s central district is too bright but its edge is too dark.
Special waterproof design, lens is separated to IR LED totally, water-proof, anti-dazzle and dust-proof. Easy disassembly, installation and maintain.
Suitable for all kinds of 24hours monitoring places, such as supermarket, hotel, school, uptown
With bracket (CS lens 12/16mm optional)
|
Item
|
HW-AS73G
|
HW-AS749G
|
|
Image sensor
|
1/3``SONY super HAD CCD
|
|
|
Sensor area
|
4.9mm x 3.7mm
|
|
|
Signal system
|
PAL/NTSC
|
|
|
Effective Pixels
|
PAL:500(H) x582(V)
NTSC:510(H) x492(V)
|
PAL:752(H) x582(V)
NTSC:769(H) x494(V)
|
|
TV lines
|
420TV line
|
540TV line
|
|
Illumination
|
0 Lux(with IR on)
|
|
|
Lens
|
16mm/F1.2
|
|
|
S/N Ratio
|
More than 48dB
|
|
|
E-shutter
|
1/50(1/60)~1/100.000(s)
|
|
|
White balance
|
Auto
|
|
|
Effective distance
|
50m
|
|
|
IR wavelength
|
850 mm
|
|
|
Protection
|
IP66
|
|
|
Video output
|
1.0vp-p.75Ω(BNC)
|
|
|
Power
|
DC 12V± 0.5% (500mA)
|
|
|
Working temperature
|
-10℃～+50℃
|
|
|
Size
|
|
|
|
G.W
|
|
|
