Specifications
A, main technical parameters of decoiler
1. Decoil type, hydraulic tense, motor-driven decoil
2. Decoiler motor power, 4KW
3. Decoiler hydraulic tense oil-pump motor power, 3KW
4. Steel coil inner diameter, φ508㎜, φ610㎜
5. Steel coil external diameter, maxφ1500㎜
6. Steel coil width, 1000mm,1250㎜
7. Bearing weight, 5T
8. Material, SUPER GALUM, galvanized sheet, color plate, mild steel
9. Decoil line speed, 0-20m/min
10. Uncoil hydraulic system pressure,10MPa
11. Control type, multistage auto tracking
12. Machine outline size, 2600mm×1400mm×1700mm
13. Control voltage, three phase, 380V, 50HZ
14. Hydraulic voltage, DC24V
B, Hydraulic loading device
1)Hydraulic promotion and demotion hydro-cylinder route, 500mm
2)Loading device route, 2.5m
3)Hydraulic system pressure, 6Mpa
Hydraulic loading device is composed of steel structural welding body, V type elevating, hydraulic pressure hydro-cylinder, hydraulic motor routing system, and steel track.
C , Delivery
Within 30days after the contract date.
D, Warranty, Year warranty
D, Warranty, Year warranty
During the warranty period, maintain and change the spare parts for the customers for free (except for the instrument damage caused by human factors or natural disasters.) And provide technical support for life-long.
Passing CE, Guaranteed quality,
PLC control system, Easy to handle
Whole-process technical trace service
Direction to production line operation
Design according to your requirements.
PLC control system, Easy to handle
Whole-process technical trace service
Direction to production line operation
Design according to your requirements.
