Jiangxi Siton Machinery Manufacturing Co., Ltd.
China Manufacturer with main products: Mucking Loader, Haggloader, Drilling Jumbo, Scooptram, Shuttle Car, Side Dumping Car |
Related products from verified members
| Export Markets: | North America, Africa, Mid East, Eastern Asia |
|---|---|
| Place of Origin: | Jiangxi in China |
| Packaging Details: | no packing |
Specifications
|
Serial number
|
Item
|
Unit
|
Numerical value
|
|
|
LWL-120 and ZWY-120/55L
|
||||
|
1
|
The whole weight (adding oil)
|
kg
|
≈16800
|
|
|
2
|
Loading ability
|
m3/h
|
≈120
|
|
|
3
|
|
|
|
|
|
4
|
Excavation width
|
mm
|
≤5800
|
|
|
5
|
Excavation distance(from shovel)
|
mm
|
≤2650
|
|
|
6
|
Excavation height
|
mm
|
≤3100
|
|
|
7
|
Excavation depth
|
mm
|
≤770
|
|
|
8
|
Loading height
|
mm
|
1680～1913(Adjustable)
|
|
|
9
|
Uninstalling distance
|
mm
|
1992(Adjustable)
|
|
|
10
|
Walking speed
|
m/s
|
0.6±5%
|
|
|
11
|
Scraper chain Speed
|
m/min
|
44
|
|
|
12
|
Scraper chain
|
|
double /single
|
|
|
13
|
Climbing slope ability
|
°
|
≤25(Solid ground)
|
|
|
14
|
equal to working slope
|
°
|
≤18
|
|
|
15
|
The least turning radius
|
m
|
≤7
|
|
|
16
|
Rating work pressure
|
MPa
|
≤25
|
|
|
17
|
Grounding ratio pressure
|
MPa
|
≤0.087
|
|
|
18
|
Clearance from floor
|
mm
|
≥338
|
|
|
19
|
The whole power
|
kW
|
55
|
|
|
20
|
joy stick
|
|
hydraulic
|
|
|
21
|
Track's inboard width
|
mm
|
1130
|
|
|
22
|
Max.material size(Depth*Height)
|
mm
|
780*820
|
|
|
23
|
Boom Max angle
|
°
|
±55
|
|
|
24
|
External dimension(transportation)
|
Length
|
mm
|
≥8900
|
|
Width
|
mm
|
2350
|
||
|
Height
|
mm
|
≥2390
|
||
|
25
|
External dimension(working)
|
Length
|
mm
|
≥10580
|
|
Width
|
mm
|
2350
|
||
|
Height
|
mm
|
≥2514
|
||
|
26
|
Fuel-tank capacity
|
|
L
|
320
|
