Shenzhen Tenglongda Optoelectronics Co., Ltd.
China Manufacturer with main products: LED Street Light, LED Flood Light, LED High Bay Light, LED Tunnel Light, LED Projection Light, LED Tube Light, LED Bulb |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | 1pcs/box |
Specifications
Main Parameters:
? Input Voltage: AC90-295V, 47-63Hz
? LED QTY: 4*(40 x 1W)( multi-chip)
? Total Power: 176±2W
? Diver Efficiency: >93%
? Harmonic distortion (THD): < 10%
? Power Factor(PF): >0.95
? LED Efficiency: >90 lm/w
? Initial LED Lumen: >14400 lm
? LED Work Voltage:30-34V
? Related color temperature(CCT):
Cool White:6000-7000K, Pure White: 4500 – 5500K, Warm White: 3000 – 4000K
? TLD define the exact range as: 3500±200K, 4000±250K, 4500±250K, 5000±300K, 6000±350K, 6500±500K
? Other available Color: red, yellow, blue, green amber
? Color Rendering Index (CRI): CW/PW: Ra≥80; WW :Ra≥70
? (50%)beam angel 132.20°
? Distribution of the light: LED+ secondary distribution of the light reflector
? The curve of light distribution: Similar to batwing /rectangle spot
? Protected Grade: IP65
? Working Temperature: -40 ºC ~ 50 ºC
? Working Humidity: -10 ~ 90%RH
? Storage Temperature: -25 ºC ~65 ºC
? Material for light : High purity Aluminum+heat dissipation section+aluminum reflector+toughened glass
? Color for driver casing, radiator: black, other colors available
? Lifespan for LED lighting source: > 50,000 hours
? Lamp pole installing diameter: ￠60mm
? Input Voltage: AC90-295V, 47-63Hz
? LED QTY: 4*(40 x 1W)( multi-chip)
? Total Power: 176±2W
? Diver Efficiency: >93%
? Harmonic distortion (THD): < 10%
? Power Factor(PF): >0.95
? LED Efficiency: >90 lm/w
? Initial LED Lumen: >14400 lm
? LED Work Voltage:30-34V
? Related color temperature(CCT):
Cool White:6000-7000K, Pure White: 4500 – 5500K, Warm White: 3000 – 4000K
? TLD define the exact range as: 3500±200K, 4000±250K, 4500±250K, 5000±300K, 6000±350K, 6500±500K
? Other available Color: red, yellow, blue, green amber
? Color Rendering Index (CRI): CW/PW: Ra≥80; WW :Ra≥70
? (50%)beam angel 132.20°
? Distribution of the light: LED+ secondary distribution of the light reflector
? The curve of light distribution: Similar to batwing /rectangle spot
? Protected Grade: IP65
? Working Temperature: -40 ºC ~ 50 ºC
? Working Humidity: -10 ~ 90%RH
? Storage Temperature: -25 ºC ~65 ºC
? Material for light : High purity Aluminum+heat dissipation section+aluminum reflector+toughened glass
? Color for driver casing, radiator: black, other colors available
? Lifespan for LED lighting source: > 50,000 hours
? Lamp pole installing diameter: ￠60mm
