Flat Roof Metal Truss
| FOB Price: | 1.00 - 80.00 USD/Meter |
|---|---|
| Supply Ability: | 10,000 Meter per Month |
| Shipping: | 10 days after 50% deposit |
| Payment Terms: | T/T |
Related products from verified members
-
Price:1.00 USD/Square MeterMin. Order:1 Square Meter -
Price:220.00-400.00 USD/Metric TonMin. Order:1 Metric Ton
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | carton,air bubble film |
Specifications
1. Truss Material: Aluminium alloy 6061/T6
2. Length Available: 1m/2m/3m/4m
3. Truss demension avaliable:
L*W(mm):250*250/300*300/350*350
i. 400*400/450*450/500*600,
ii. 520*760/600*760
4. Thickness: 3mm
5. Main tube: 50mmx3mm
6. Brace tube: 25mmx3mm
7. Connection Mode: Bolt connection/ spigot connection
8. Shape: square, triangle, layer,circle ,etc.
9. Usage:
We can design diverse shapes to hang acoustics,speaker,
lighting and so on.
We can design diverse shapes to hang acoustics,speaker,
lighting and so on.
10. Features:
Lighting truss hanging lights,loud speaker.Suitable for displays,
exhibition, performance show, concert, event etc.. Finish in a
spigot or screw as your request. Convenient for set up and transportation
exhibition, performance show, concert, event etc.. Finish in a
spigot or screw as your request. Convenient for set up and transportation
11. Weight Capacity:
200-800KG/Meter according to the truss size
12. Most Characteristics:
All kinds of truss can be retread and reused because it have high
corrosion resistence, non-rust with high technical welder and good
quality of alloy aluminium tube. It can help you to save the expendition.
corrosion resistence, non-rust with high technical welder and good
quality of alloy aluminium tube. It can help you to save the expendition.
13. Certification:
CE,ISO9001certificated
Aluminium Bolts Truss System
(L15m*W10m*H8m)
|
Item
|
Name
|
Specification
|
Quality
|
Unit
|
Unit Price
|
|
|
1
|
Bean truss
|
500mm*600mm
|
50
|
meter
|
30USD
|
|
|
2
|
Tower truss
|
400mm*400mm
|
32
|
meter
|
38
|
|
|
3
|
Sleeve block
|
550*550*400mm
|
4
|
pc
|
20
|
|
|
4
|
Base shief Joint
|
550*550*120mm
|
4
|
pc
|
15
|
|
|
5
|
Steel base
|
550*550*200mm
|
4
|
pc
|
20
|
|
|
6
|
stabilizer
|
1.5m long
|
8
|
pc
|
25
|
|
|
7
|
Top section
|
Aluminum alloy
|
4
|
pc
|
30
|
|
|
8
|
Hander hoist
|
Electricity
|
4
|
pc
|
50
|
|
|
9
|
belts
|
|
4
|
pc
|
20
|
|
