Battery-powered electromagnetic flow meter

Inquiry Now

Specifications

Characteristics:

1, The world's fires one achieving the cross time significant battery-powered electromagnetic flow meter, guarantees on-line measurement accuracy effectively.

2, First international leading excitation technology, excitation circuit is simple, stable and reliable.

3, High resistance fast response design, no distortion collects weak signals and reacts flow changes, range ratio can reach 100:1.

4, With low conductivity measurement function.

5, With the consistency of the exchange converter, it need not to check parameters again.

6, Provided sensor zero correction and zero self-adjustment function.

7, Chinese (English) friendly interface, satisfies all parties use requirement.

Technical parameters:

1, Diameter: DN10~DN1200

2, Measurement range: 0.05m/s~10m/s

3, Accuracy: 0.4m/s~10m/s is 0.5 grade, 0.1m/s~0.4m/s is 1 grade.

4, Repeatability: a third of the measured value.

5, Chinese and English display: transient flow, velocity, percentage flow and positive and negative cumulative total net can be set, and alarmed.

6, Output signal: frequency : 0~5kHz amplitude: 24V passive: RS485; GPRS communication.

7, Excitation way: high frequency excitation.

8, Excitation frequency: 1/4, 1/2 it can be chosen through setting.

9, Power supply: 3.6VDC power: <2mW
