Series JZS Engine Oil Regeneration System

Inquiry Now

Related products from verified members

Online Load Tap Changer Oil Purifier

Price:5,000.00-20,000.00 USD/Set

Min. Order:1 Set
JZL Insulating Oil Regenerating Appropriative V...

Price:0.10-0.20 USD/Set

Min. Order:1 Set
CNC Oil Mist Purifier for Machine Tools

Price:

Min. Order:10 Sets
Waste Lubrication Oil Decolorization / Oil Recy...

Price:

Min. Order:1 Set

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

Application:

Series JZS engine oil regeneration system is mainly for regenerating the waste engine oil, this equipment can effective separate water, gas, particles, deeply oxides, free carbon, colloid, asphalt and wax from oil, making black engine oil become transparent golden color. This equipment has the functions of dewatering, degassing, decolor. Improving the engine oil' s properties, restoring the oil' s performance and lowering wear to ensure the engine can work normally and safely, prolonging the engine and engine oil lifetime.

Features:

1. Use of special chemicals to eliminate oil-ion' s charge polarity, collecting oil-ions and separating out them, removing colloid, asphalt and other chemical compounds.

2. Gas treatment device combined with air filter and vacuum degassing, dewatering to remove the odor and water.

3. Closed type filtering system use stainless steel mesh, reliable, no pollution. Two filtering units can realize continuous production.

4. Vacuum degassing, dewatering, removing particles make sure effectively improve oil properties, restoring oil performance.

5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

6. Compact structure, reasonable layout, small space applied, large output.

7. Imported Germany electric parts (such as SIEMENS, SCHNEIDER), good performance, safe and reliable.

Technical parameters:

Index name	unit	JZS-1000	JZS-2000	JZS -5000	JZS-10000
Flow rate	L/Day	1000	2000	5000	10000
Ratio of regeneration	%	75 -95
Working pressure	MPa	-0.095 ～ 0.4
Temperature range	C	80～180
Working noise	dB(A)	≤ 70
Power supply		380V 50HZ 3PH(As per user' s option)
Heating power	kW	55	108	145	192
Total power	kW	68	122	162	216
Inlet(Outlet)	mm	32	32	42	42
Reactor system	mm	2500x2100x2300	3000x2100x2300	3300x2100x2300	5600x2100x2300
Filtration system	mm	3000x1200x1900	3000x1400x1900	3500x1600x2100	2x3500x1600x2100
Gas treatment system	mm	1360x800x3000	1360x800x3000	1560x950x3000	1560x950x3000
Weight	kgs	3100	4200	6700	8800
