Steyr King Concrete Transporta Truck

FOB Price:	60,000.00 - 100,000.00 USD/Set
Supply Ability:	2,000 Set/Sets per Year
Shipping:	Based on the quantity
Payment Terms:	L/C, T/T, Bank transfer

In Stock

Inquiry Now

Product Details

Export Markets:	North America, Africa, Mid East, Eastern Asia
Place of Origin:	Hubei in China
Packaging Details:	nude, waxed, etc.

Specifications

Steyr King Concrete Transporta Truck

1. Cab: It adopts new type of standard cab of STEYR King. It is installed with STEYR King 5001 new internal trim and appliance and so on and set with simple sleeper inside. It is comfort for driving and handy for operation; The appearance is new type of STEYR King standard cab of attractive and elegant appearance which maintains the fine hereditability with STEYR King cab.

2. Engine: CNHTC adopts the special used WD615.68A 6-cylinder straight boosting diesel engine with the rated power being 225kW/2200r/min, maximum torque being 1250N. M/1300-1500r/min; it satisfies the emission limit at Euro 2 stage.

3. Clutch: Hydraulic operation air power assisted operation mode, reinforced single plate dry spiral spring clutch, φ 420mm.

4. Transmission: Mature Fuller RT11509C 9-shift mechanical shift transmission makes the product quality more reliable. It has high generalization with STEYR series product. The spare parts can be timely provided in convenience for maintenance.

5. Tubular shape, open type, flange φ 165, flat plate, shaft tube 93*7, more reliable torque transfer.

6. STEYR one and two steering front axle, rear double-driving axle is STEYR driving axle with hub reduction for STEYR batch assembly which makes the fuel economical property of the product optimal.

7. Utilization of ZF8098 steering gear maintains the good inheritance with STEYR series product which makes the steering property of the product more stable and reliable.

8. Frame: equivalent width trapezoidal frame, (243× 80× 8+218× 70× 5)mm channel section parallel girder, channel beam with wide connecting plate.

9. Rim and tire: 8.50-20 two-piece rim; 12.00-20-18PR diagonal tire.

Product model number		ZZ 1316M4666V	Rear wheel track	1800,1830(mm)
Corresponding original model number		W266/O46/8× 4V	Front axle	STR
Bulletin Batch		2001A8	Driving axle	STR
Engine	Model	WD615.62	External dimension of the tank( length × diameter)	8550× 2100 (mm) Non-head length of
	Power	196(KW)	Internal dimension of the van(length × width × height)	7000× 2300× 1500(mm)
	Place of production	CNHTC	Number of leaf spring (front/rear)	Front14 rear 13/12
	Fuel type	Diesel	Cab	SW92
Total mass		31000(kg)	Transmission	F8
Kerb mass		14300	Steering gear box	German ZF
Rated loading mass		16570(kg)	Tire quantity	12
Maximum velocity		90(km/h)	Tire specification	12.00-20, 11.00-20
Axle number		4	Approach angle/departure angle	15/17
Wheel base		1800+4600+1350(mm)	Front overhang /rear suspension(mm)	1560/2680
Front wheel tread		1939,1958(mm)	Identification ID	LZZZBXEF × × × × × × × × ×
