Polyester Paper-making Screen

Shipping:	XINGANG TIANJIN
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Hebei in China

Specifications

3-shed monofilament weaving dryer fabric is mainly used in the dryer section of paper making industry or used in the dryer section in other industry .The fabric is level and flat with close . lt is suitable for cultural paper ,printing paper ,offset ,thinner paper and the deferent belt of other equipments.

Mode	Dia .Of Monofilament	Quantity of Ap
Gw22503	0.50 *0.50	8000

At permeability of 4-shed monofilament weaving dryer fabric is higher and thicker that 3-shed monofilament fabric, witch good size stability and long-life .The fabric is suitable for writing, pinting, making culture, packing and base paper of corrugated paper .It also can be used as desiccators and deferent belt of other equipments.

Mode	Dia .Of Monofilament	Quantity of Ap
GW22504	0.50 *0.50	12000

According to Finland Standard with first-class monofilament, which make the polyester dryer spiral, has the characteristics of stable property and long work time .The fabric is extensively used for producing cardboard, Kraft paper, corrugated paper, paper for train fare, single tow-sided, paperboard, replacing papermaking machine dry blandet, canvas. Extensively apply to the deferent belt of the equipment in the trade, such as colliery, food medicine.

Mode	Monocyclic Specifications	Quantity of Ap
Large loop	LW 4.0 *8.0mm	20000 ?500
Medium loop	LW3.8 *6.8mm	18500 ?500
Small loop	Lw3.2 *5.2mm	15000 ?500

Spiral pigeonhole filter fabric suitable for high pressure is it stain person person who washes thick liquid topigeonhle, level taking type washes the thick liquid machine ,size person who separate and coal washing network bringing type coal machine of trade ,in print and dye ,food ,salt industry ,pharmacy environmental protection, process hides ,shoes material ,clothing pottery, other mechanical conveyer belt etc .already extensive application too among trade .

Mode	Monocyclic Specifications	Quantity of Ap
Large loop	LW 4.0 *8.0mm	5500 ?500
Medium loop	LW3.8 *6.8mm	4750 ?500
Small loop	Lw3.2 *5.2mm	4000 ?500

4-shed single fabric is standard type of polyester polyester forming fabric in paper making mainly used for producing cultural paper, printing paper, packing paper and so on

Mode	Dta.of warp &weft	Aperture Size	Openness
CXW27254	0.20 *0.25	0.33 *0.24	18.00
CXW27274	0.20 *0.27	0.133 *0.195	16.8
CXW31204	0.18 *0.20	0.12 *0.139	17.8

8-shed single layer fabric is the most wear-resisting one in the sing layer fabrics, which have long performance life, but mesh print is relatively deep .It is mainly sued for copying the bag, Kraft paper, cardboard, corrugated paper and so on.

Mode	Dta.of warp &weft	Aperture Size	Openness
CXW25358	0.22 *0.35	0.137 *0.176	12.90
CXW27358	0.20 *0.35	0.133 *0.163	12.7

Seven shed double layer fabric is suitable for making fine paper and low basis weight papers.

Mode	T-value	Water permeability
CXW56188	100-110	58-68
