Delong Machinery Equipment Factory
China Manufacturer with main products: Insulation Forming Machine, Insulating Machine, Coil Inserting Machine, Coil Winding Machine, Shaping Machine, Coil Inserting Machine Mould,... |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
Specifications
coil winding machine (DLM-400)
1.Double vertical.
2.Excellent quality and competitve price
1. It is horizontal and automatic winding machines with serial parallel coil formers,which is suitable for winding various AC,DC motor stator coil and inductance coil.
2. It is controlled by a single board computer,and a stepping motor can automatically complete the operations such as zero resetting,traversing and skipping so as to realize exact lining.
3.Through the control panel,users can set the wire diameter,number of turns,through of traverse and skipping distance,etc.according to their demands.
Technical Parameter
|
Parameter
|
DLM-500
|
|
Max winding speed
|
2000 rpm/min
|
|
Max suitable coil segments
|
6
|
|
Suitable wire diameter
|
0.3-1.3 mm
|
|
Max coil down-lead
|
500 mm
|
|
Suitable motor poles
|
2\4\6\8
|
|
Max coil down-lead
|
260 mm
|
|
Input
|
380V/50Hz
|
|
Air pressure
|
0.5-0.8 MPa
|
|
Power
|
9000 W
|
|
Dimension
|
2000mm×2000mm×2300mm
|
|
Weight
|
about 1600 kg
|
