TigerTec Inc.
China Manufacturer with main products: CNC Router, CNC Machine, CNC Engraving Machine, Engraving Machine, Woodworking Machine, CNC |
TR203-1 CNC ROUTER
| Supply Ability: | 80 Set/Sets per Month |
|---|---|
| Shipping: | 25-35days |
| Payment Terms: | L/C, T/T, D/P |
Related products from verified members
| Export Markets: | North America, South America, Southeast Asia, Africa, Eastern Asia |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | wood case |
Specifications
| Item | Description | Parameter |
| 1 | X, Y, Z working area | 600X900X100mm |
| 2 | Table size | 710X1100mm |
| 3 | Resolution | ± 0.03/300mm |
| 4 | Repeatability | ± 0.02mm |
| 5 | Lathe structure | Cast steel |
| 6 | X structure | Ball screw, shaft rails |
| 7 | Y structure | Ball screw, linear rails |
| 8 | Z structure | Ball screw, shaft rails |
| 9 | Max. consume power | 3Kw |
| 10 | Max. rapid | 0-6000mm/min |
| 11 | Max. working speed | 0-3000mm/min |
| 12 | Spindle power motor | 1.5kw chinese self-coolant spindle, ER16 |
| 13 | Spindle speed | 0-24000RPM |
| 14 | Working mode | Stepper motor |
| 15 | Working voltage | Single phase AC220V/50HZ/60Hz |
| 16 | Command code | G Code(*uoo,*nc,*mmg, *plt) |
| 17 | Operating System | DSP system or Mach3 system |
| 18 | Interface | Printer port 50pins or USB |
| 19 | System memory | 128M (or pen driver) |
| 20 | Collet | ER16 |
| 21 | X, Y working delicacy | <0.01mm |
| 22 | Software | Type3 software, ucancam software, copy artcam software |
| 23 | Running circumstance |
Temperature: 0℃～45℃ relative humidity: 30%～75% |
| 24 | Packing size | 1380X1080X950mm |
| 25 | Net weight | 140KG |
| 26 | Gross weight | 250KG |
