LB-2261A hinge/two way hinge/two sections strength hinge/Full-hinge

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

                                        JIEYANGSHI LINBO HARDWARE CO.,LTD

type:LB-2261A LB-2261B   LB-2261C
Other name:hinge/two way hinge/two sections strength hinge/Full-hinge/door hinge
Opening angle:90-110'
Weight:60g/pc
Door thickness:14-24mm
Door(K) dimension:3-7mm
Times of on-off:6-8 Ten thousands
Material: iron
Surface:copper & nicke
Hole distance:48mm
Diameter of hinge cup:35MM
Depth of hinge cup:11.5mm
Cup fixed:Wood screws M4*16mm
Packing quantity:200pc/box
Size box:37*31*20cm
Standard:Full-overlay   Half-overlay Inset

cupboard door installtion method

Full-overlay
      The plank covers the side plate of the cupboard door completely.with a gap between them,in order to open the door smoothly.

Half-overlay
      In this case,two doors use one side plate,with a required minimal gap between them,so the covered distance of each door is decreased accordingly, therefore,the curve-armed hinge is needed.

Inset
      In this case,two door is fixed by the side plate of the inner cupboard.It also needs a gap,in order to open the door smoothly.a hinge with very quite curved arm is needed.
