Huizhou V-Way Energy Technology Co., Ltd.
China Manufacturer with main products: Solar Power System, Solar Charge Controller, Solar Inverter, Solar DC Water Pump, Wind&solar Hybird Controller, Solar Power Station,... |
Wind Turbine
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
| Wind Turbine | |||||||||||||||
| Model | 50W | 100W | 300W | 400W | 600W | 1KW | 2KW | 3KW | 4KW | 5KW | 7.5KW | 10KW | 15KW | 20KW | 30KW |
| Rated power | 50W | 100W | 300W | 400W | 600W | 1000W | 2000W | 3000W | 4000W | 5000W | 7500W | 10KW | 15KW | 20KW | 30KW |
| Maximum power | 65W | 150KW | 400W | 500W | 750W | 1500W | 2600W | 4000W | 5000W | 7000W | 10500W | 15KW | 17.5KW | 26KW | 34KW |
| Wind wheel diameter | 0.83M | 1.2M | 2.2M | 2.2M | 2.5M | 2.8M | 3.2M | 4M | 5M | 5M | 6M | 7M | 8M | 10M | 12M |
| Leaf number | 3pcs | 3pcs | |||||||||||||
| Blade material | Glass reinforced plastic | Glass reinforced plastic | |||||||||||||
| Motor type | Three-phase Sychronous Generator with permanent magnetic | Three-phase Sychronous Generator with permanent magnetic | |||||||||||||
| Starting torque | 0.15NM | 0.20NM | 0.25NM | 0.3NM | 0.35NM | 0.4NM | 0.8NM | 2.5NM | 3.8NM | 4.5NM | 6.7NM | 7.5NM | 9.6NM | 10NM | 11.5NM |
| Starting wind speed | 1.5m/s | 1.5m/s | 2.5m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s | 3m/s |
| Cut out wind speed | 15m/s | 15m/s | 18m/s | 18m/s | 18m/s | 18m/s | 18m/s | 18m/s | 18m/s | 18m/s | 20m/s | 20m/s | 25m/s | 25m/s | 25m/s |
| Rated wind speed | 8m/s | 8m/s | 8m/s | 8m/s | 8m/s | 8m/s | 10m/s | 10m/s | 10m/s | 10m/s | 12m/s | 12m/s | 12m/s | 12m/s | 12m/s |
| Safe wind speed | 45m/s | 45m/s | |||||||||||||
| Ambient temperature | (-45℃/70℃) | (-45℃/70℃) | |||||||||||||
| Rated voltage | 12-24VDC | 24VDC | 24-220VDC | 24-350VDC | 24-350VDC | 56-240VDC | 56-500VDC | 120-500VDC | 120-500VDC | 240-500VDC | 240-500VDC | 240-500VDC | |||
| Body weight | 15kg | 20kg | 38kg | 38kg | 48kg | 71kg | 88kg | 110kg | 310kg | 410kg | 500kg | 1250kg | 1350kg | 1500kg | 1625kg |
| Price ( USD) | 147 | 202 | 248 | 314 | 378 | 673 | 863 | 1160 | 2380 | 3430 | 3830 | 7230 | 7740 | 10350 | 13300 |
