GPS Time Synchronizer (TF 1581)

Supply Ability:	200 Set/Sets per Month
Shipping:	15 business days after the order has been confirmed
Payment Terms:	L/C, T/T

Inquiry Now

Related products from verified members

Portable Full-function Cellphone & GPS Jamm...

Price:70.00-75.00 USD/Piece

Min. Order:1 Piece
GPS Receiver F20 Static

Price:

Min. Order:1 Set

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Beijing in China
Packaging Details:	master carton: 54x44x22 cm

Specifications

Dimension	440mm(19'')
Height	44mm(1U)/88mm(2U)
Operating temperature	-10~+55
Width	340mm
Storage temperature	-25~+70
Weight	3KG
Relative humidity	5%-95%(no dewdrop)
Power input voltage	220V AC/DC 110V AC/DC
Permit deviation	+/-15%
Power consumption	<=10W

1. High-accuracy time service.
2. nanosecond level.
3. Suitable to be used in different time zones,strong anti-interference

1. Model TF1581 GPS Time Synchronizer, developed based on European time-frequency cutting-edge technologies, is a high accuracy and high availability time synchronization device, which can receive wireless signals simultaneously that are sent by 12 GPS space satellites, such that it can provide users with standard time, and is an ideal device for the establishment of accurate time scales and realization of time synchronization.

2. The design of Model TF1581 GPS Time Synchronizer takes into full consideration the diversity of customers' demand, provided with GPS standard time signal input, and output signals types, like 1PPS/1PPM/1PPH pulse and RS232/RS422/RS485 serial port, thus it can satisfy the requirements of different devices and applications.

3. Based on standard configuration, IRIG-B time reference input can be added to realize dual redundancy setting and ensure infallible time source; built-in OCXO can be added, so as to ensure time keeping and time service upon occurrence of loss of signal; NTP network time server interface or DCF77 output signal can also be added. Therefore, TF1581 can be used as master clock in centralizing time service and time synchronization system.

4. This user manual is the description of standard configuration, out-going output signal and quantity shown as follows:

1PPS x 4, 1PPM x 8, RS-232 x 1, RS-422 x 1, IRIG-B/AC x 1,
IRIG-B/DC x 2 , NTP x 1 ,PPS(TTL) x 1, ALARM x 1.
