Flexible High Efficiency Truck Mounted Sweeper
Flexible High Efficiency Truck Mounted Sweeper
This type of trcuk mounted sweeper is designed to clean up freeways, trunk highways, county roads, urban roads, scenic spot roads, and airport roads. It works by picking up gravel, rind, scrap of paper, cigarette end, kernel, plastic bag, stone, brick, grains of sand, dust, and etc.
Flexible High Efficiency Truck Mounted Sweeper Features :
l Modified on two types of chassis of HFC1053K2T or JX1061T23, this sweeper is equipped with air conditioning, heater, power steering system, and high-quality CD player, making driving easy.
l This equipment is an environment-friendly special purpose sweeper, which integrates sweeping, sprinkling, and garbage transportation.
l The cleaning system is driven by imported advanced hydraulic motor to guarantee the power and reliability during work.
l When cleaning, the sweeping brushes softly contact the ground, largely reducing their wear and extending their working life.
l The suction unit features elastic collision and avoidance to ensure the safety during the cleaning process.
l Equipped with oversized three layers of filter system, dust filtering ratio up to 99.99%, extending engine’s life.
l The hydraulic motor is imported from Bulgaria, stable operation.
l Equipped with a backup hydraulic unit, which is used to perform some actions, in case the truck can not start.
l The main and auxiliary engines are from the same brand, so it’s relatively easy to maintain.
l Stainless steel water tanks, garbage can makes the working life longer.
Flexible High Efficiency Truck Mounted Sweeper Technical Parameters:
|
Model
|
YHQS5050A
|
|
Chassis parameters
|
|
|
Manufacturer
|
JMC
|
|
Model
|
JX1061TG23
|
|
Wheel base
|
3360 mm
|
|
Total mass
|
5880 kg
|
|
Curb weight
|
4640kg
|
|
Loading mass
|
1805 kg
|
|
Engineinsitu parameters
|
The main and vice-engine are the same, easy maintenance
|
|
Manufacturer
|
JMC
|
|
Model
|
JX493ZLQ3(Euro III)
|
|
Output rating
|
85 kw 3600 rpm
|
|
Vice-engine parameters
|
|
|
Manufacturer
|
JMC
|
|
Model
|
JX493G3(Euro III)
|
|
Output rating
|
57 kw 3600rpm
|
|
Sweeping system parameters
|
|
|
Sweeping width
|
3.0 m
|
|
Sweeping speed
|
4-25 km/h
|
|
Maximum cleaning ability
|
86000 m³
|
|
Sweeper parameters
|
|
|
Quantity
|
4
|
|
Diameter
|
800 mm
|
|
Control system
|
Hydraulic system
|
|
Material
|
Wearproof nylon(add wire)
|
|
Fan parameters
|
Custom fun,Japanese original bearing
|
|
Rated revolution
|
2900rpm
|
|
Blowing rate
|
16000 m³/h
|
|
Blast pressure
|
7500 pa
|
|
Vacuum cups parameters
|
Adjustable,to ensure ground clearance
|
|
Width
|
680 mm
|
|
Suction tube diameter
|
240 mm
|
|
Dustbin parameters
|
Stainless steel, airtight test
|
|
Dustbin capacity
|
5 m³
|
|
Water system
|
Double filtration system
|
|
Water tank capacity
|
1200L
|
|
Number of nozzles
|
18
|
|
Others
|
|
|
Overall dimensions
|
5750X2120X2660 mm
|
|
Minimum turning diameter
|
13.6m
|
|
Maximum running speed
|
100km/h
|
