Henan Xingyang Mining Machinery Manufactory
China Manufacturer with main products: Crusher Series, Ball Mill, Spiral Classifier, Flotation Machine, Magnetic Seperator, Mineral Process Line, Stone Crushing Line, Sand Making... |
Mining Ball Miller / Ball Miller Grinding Machine
| FOB Price: | 180,000.00 - 680,000.00 RMB/Set |
|---|---|
| Supply Ability: | 50 Set/Sets per Month |
| Shipping: | 25-40 working days after receiving your downpayment |
| Payment Terms: | L/C, T/T, Paypal, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | standard container or as your request |
Specifications
1) High-quality materials
2) Exquisite workmanship
3) Low-cost high-quality full-service market
2) Exquisite workmanship
3) Low-cost high-quality full-service market
Structure features of ball mill
This Ball miller is made up of feeding part, discharging part, gyre part, transmission part (decelerator, small transmission gear, generator, electrical control) and so on. The hollow axis adopts the cast steel and the rotary big gear is processed from cast rolling gear .The barrel body wears well and bears wearable scale board .
And compared with the traditional ball mill, the motor power of the energy-saving ball mill can reduce the power by 18-25%, lubrication of 70% and comprehensive energy-saving of over 20%.And during the normal function, we need not to change the main axis ,which can save a lot of maintenance cost and time .And the main bear adopt oil grease ,which is convenient to avoid the heavy metal pollution.
This Ball miller is made up of feeding part, discharging part, gyre part, transmission part (decelerator, small transmission gear, generator, electrical control) and so on. The hollow axis adopts the cast steel and the rotary big gear is processed from cast rolling gear .The barrel body wears well and bears wearable scale board .
And compared with the traditional ball mill, the motor power of the energy-saving ball mill can reduce the power by 18-25%, lubrication of 70% and comprehensive energy-saving of over 20%.And during the normal function, we need not to change the main axis ,which can save a lot of maintenance cost and time .And the main bear adopt oil grease ,which is convenient to avoid the heavy metal pollution.
Technical parameter table
|
Model
|
Speed
(r/min)
|
Loading
(t)
|
Feeding size
(mm)
|
Discharge size
(mm)
|
Yield
|
Power
(KW)
|
Weight
(t)
|
|
(t/h)
|
|||||||
|
900×1800
|
3638
|
1.5
|
≤20
|
0.075-0.89
|
0.65-2
|
18.5
|
4.6
|
|
900×3000
|
36
|
2.7
|
≤20
|
0.075-0.89
|
1.1-3.5
|
22
|
5.6
|
|
1200×2400
|
36
|
3
|
≤25
|
0.075-0.6
|
1.5-4.8
|
30
|
12
|
|
1200×3000
|
36
|
3.5
|
≤25
|
0.074-0.4
|
1.6-5
|
37
|
12.8
|
|
1200×4500
|
32.4
|
5
|
≤25
|
0.074-0.4
|
1.6-5.8
|
55
|
13.8
|
|
1500×3000
|
29.7
|
7.5
|
≤25
|
0.074-0.4
|
2-5
|
75
|
15.6
|
|
1500×4500
|
27
|
11
|
≤25
|
0.074-0.4
|
3-6
|
110
|
21
|
|
1500×5700
|
28
|
12
|
≤25
|
0.074-0.4
|
3.5-6
|
130
|
24.7
|
|
1830×3000
|
25.4
|
11
|
≤25
|
0.074-0.4
|
4-10
|
130
|
28
|
|
1830×4500
|
25.4
|
15
|
≤25
|
0.074-0.4
|
4.5-12
|
155
|
32
|
|
1830×6400
|
24.1
|
21
|
≤25
|
0.074-0.4
|
6.5-15
|
210
|
34
|
|
1830×7000
|
24.1
|
23
|
≤25
|
0.074-0.4
|
7.5-17
|
245
|
36
|
|
2100×3000
|
23.7
|
15
|
≤25
|
0.074-0.4
|
6.5-36
|
155
|
34
|
|
2100×4500
|
23.7
|
24
|
≤25
|
0.074-0.4
|
8-43
|
245
|
42
|
|
2100×7000
|
23.7
|
26
|
≤25
|
0.074-0.4
|
8-48
|
280
|
50
|
|
2200×4500
|
21.5
|
27
|
≤25
|
0.074-0.4
|
9-45
|
280
|
48.5
|
|
2200×6500
|
21.7
|
35
|
≤25
|
0.074-0.4
|
14-26
|
380
|
52.8
|
|
2200×7000
|
21.7
|
35
|
≤25
|
0.074-0.4
|
15-28
|
380
|
54
|
|
2200×7500
|
21.7
|
35
|
≤25
|
0.074-0.4
|
15-30
|
380
|
56
|
|
2400×3000
|
21
|
23
|
≤25
|
0.074-0.4
|
7-50
|
245
|
54
|
|
2400×4500
|
21
|
30
|
≤25
|
0.074-0.4
|
8.5-60
|
320
|
65
|
|
2700×4000
|
20.7
|
40
|
≤25
|
0.074-0.4
|
12-80
|
400
|
94
|
|
2700×4500
|
20.7
|
48
|
≤25
|
0.074-0.4
|
12-90
|
430
|
102
|
|
3200×4500
|
18
|
65
|
≤25
|
0.074-0.4
|
|
800
|
137
|
