Hubei Jiangnan Special Automobile Co., Ltd.
China Manufacturer with main products: Fire Truck, Aerial Platform Truck, Wrecker Truck, Garbage Truck, Sweeping Truck, Oil Truck, Water Truck, Vacuum Suction Truck |
16th
Mini Concrete Mixer Truck
| FOB Price: | 30,000.00 - 45,000.00 USD/Set |
|---|---|
| Supply Ability: | 5,000 Set/Sets per Year |
| Shipping: | 10 days |
| Payment Terms: | L/C, T/T, Bank transfer |
| Export Markets: | South America, Eastern Europe, Southeast Asia, Africa, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hubei in China |
| Packaging Details: | nude, waxed, etc. |
Specifications
Mini Concrete Mixer Truck/Hydraulic Concrete Mixer
1. Based on hundreds of experiments of discharging rate ,charging rate, mix rate, twist spring, running performance and absorbability of the experience of the mechanical design, manufacture, welding ,we have produced the concrete mixer which is the ideal transportation equipment for the commercial concrete,
2. There are various choices ranged from 3cbm-16cbm for the customers .we can choose the well-known chassis from the Europe, Japan, Chinese with powerful drive
3. Moreover, the oil pump ,motor ,and the condenser is adopted the famous foreign production to ensure the quality
4. The production above is just for reference, please contact the Ms Jessie Jin without any hesitation if you need the specific affairs requested.
5. Technical parameter:
|
Main parameters
|
Gross weight (kg)
|
12000
|
|
|
Payload weight (kg)
|
4200
|
||
|
Kerb weight (kg )
|
7605
|
||
|
Overall demension
|
Lenght (mm)
|
7950,7650
|
|
|
Wideth (mm)
|
2490
|
||
|
Height (mm)
|
3900
|
||
|
Chassis
|
Chassis No.
|
EQ3120GSZ3GJ
|
|
|
Drive
|
4 x 2
|
||
|
Wheelbase (mm)
|
4200
|
||
|
Gear box
|
DC6J
|
||
|
Front/Rear axle load
|
5T/10T
|
||
|
Front/Rear track (mm)
|
1940/1860
|
||
|
Tire
|
10.00-20
|
||
|
Max. speed (km/h)
|
80
|
||
|
Engine
|
Model
|
YC6J190-33
|
|
|
Horsepower(hp)
|
190
|
||
|
Displacement(ml) / Power (kw)
|
6494/140
|
||
|
Emission
|
Europe 3
|
||
|
Technical parameters of mixing tube
|
Stirring volume (m³)
|
6
|
|
|
Rate of feeding (m³/min)
|
≥3
|
||
|
Rate of delivery (m³/min)
|
≥1.0
|
||
|
The remaining rate (%)
|
≤1.0
|
||
|
Tube dip (°)
|
15°
|
||
|
Tube service speed (r/min)
|
70---260
|
||
|
Hydraulic drive parameters
|
Decelerator
|
Import from Italy
|
|
|
Hydraulic pump
|
|||
|
Hydraulic motor
|
|||
|
Water system
|
Type of water supply
|
Pressure water box
|
|
|
Capacity of water box (L)
|
200L
|
||
