Agilent E5052A

Inquiry Now

Specifications

The Agilent E5052A Signal Source Analyzer (SSA) is a new class of instrument that can evaluate the critical performance characteristics of nearly all types of RF and microwave signal sources. Agilent's goal in creating the SSA was to offer a single instrument that would significantly speed measurement times, and help R&D and manufacturing engineers in the wireless communications, broadband optical, aerospace/defense and electronics industries perform tests more accurately, and with unprecedented simplicity. The SSA also significantly lowers cost by eliminating the need to purchase multiple standalone instruments. While the SSA follows the tradition of Agilent's popular 4352S VCO/PLL Signal Test System, which is designed to characterize voltage-controlled oscillators (VCOs) and PLL synthesizers, it addresses the limitations of the 4352S and offers new test capabilities that enable evaluation of a much broader range of signal source types. Comprehensive Capabilities The Agilent E5052A SSA makes four types of measurements:

1. Frequency, power and DC current

2. Transient measurements (frequency, phase and power versus time)

3. Spectrum monitor

4. Phase noise

The SSA has been designed to meet or exceed current and anticipated requirements for each measurement type. Frequency, power and DC current tests are facilitated by simultaneously measuring frequency, RF power and DC current consumption. DC tuning (control) voltage and DC power sweeps enable a variety of measurements, including:

Tuning sensitivity (frequency versus DC tuning voltage)
Frequency pushing (frequency versus DC power voltage)
RF power versus either DC tuning voltage or DC power voltage
DC current consumption versus either DC tuning voltage or DC power voltage
