Dry-Method High Speed Laminating Machine

FOB Price: 10,000.00 - 20,000.00 USD/Set
Supply Ability: 100 Set/Sets per Quarter
Shipping: Ningbo Sea Port
Payment Terms: L/C, T/T, Western Union
In Stock
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: Wooden Box

Specifications

> > Dry-Method High Speed Laminating Machine Major Features & Function:

This film laminating machine are suitable for reel-shape materials such as BOPP, PET, CPP,

aluminum foil, and paper, 2-layer repetitious laminating, high strength production
, producing high-quality compound materials with high freshness preserving,
and boiling & steaming resistance.
1. Double frequency conversing synchronic timing is adopted for entry port of main machine,
making more stable operation.
2. Two means of glue applying, cob webbing roll sizing and rubber roll gluing
3. Top air style oven open, initiative guiding roll in oven.
4. 4-sect heating in drying tunnel, possible to control temperature by segments
5. Photoelectric error correction for unreeling, with automatic tension
6. Reeling and unreeling by tumbling dual-station mechanism,
realizing auto material change without machine halt.
7. Oil warming system for composite reel, constant temperature control.


> > Major Technical Parameters:
Type
DFG-600
DFG-800
DFG-1000
Laminating Width
600mm
800mm
1000mm
Laminating Stratification
2 Layers
2 Layers
2 Layers
Laminating Speed
10-140m/min
10-140m/min
10-140m/min
Diameter of roll material
800mm
800mm
800mm
Oven Temperature
120℃
120℃
120℃
Total Power
44kw
48kw
52kw
Weight
7500kg
8200kg
8900kg
Overall Dimension
9.6*2.4*3.3m
9.6*2.65*3.3m
9.6*2.85*3.3m
