LED Digital Billboards

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	wooden case or flight case

Specifications

P10 HD(High Definition) LED Digital Billboard
Technical Specifications
LED Lamp Parameters
No.	Item	Specifications
1	LED lamps	DIP346 , Oval
2	Wavelength	Red LEDs	620-630nm
		Green LEDs	520-535nm
		Blue LEDs	465-475nm
LED Module Specifications
1	Pixel Pitch	10mm
2	Pixel Configuration	1R1G1B
3	Module Resolution	16dots X 16dots
4	Module Size	160mm x 160mm
LED Cabinet Specifications ( Standard Cabinet )
1	Cabinet Size(WxH)	960mm x 800mm
2	Cabinet Resolution	96 x 80 pixel dots
3	Module Quanity	30 PCS
4	Cabinet Frame Material	black powder coated steel
5	Cabinet Weight	46Kg
