LED Tunnel Light 120w

Inquiry Now Start Order

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	BOX

Specifications

1. led tunnel light,tunnel light,tunnel lights,

2. Power: 120w led tunnel light,

3. Power optional:120w,160w,200W,

4. Waterpoof IP65 led tunnel light

Model Number	HM-LTL2*60W
LED Consumptions	109W
System Consumption	125W
LED Initial Flux	WW	PW	CW
	8938 Lm	9265 Lm	9047 Lm
Power Factor	>0.95
Total Hamornical Distortion	<9%
Power Efficiency	>87%
Lighting Efficiency	>85%
Installation Height	(Height) 6M	(Height) 8M	(Height) 10M
Average Illuminance	>45.6 lux	>27 lux	>20 lux
Illumiance Area	10 x 10 m	14 x 14 m	17 x 17 m
Illuminance Uniformity	>0.6
Color Rendering Index	WW		CW
	Ra >68	Ra >75	Ra >75
Beam Angle	120°
Working Voltage	DC 30 ~ 36V
Input Voltage	AC 85 ~ 265V
Frequency	50 ~ 60 Hz
LED Junctin Temperature	≦80℃
Working Temperature	-40℃ ~ +55℃
IP Grade	IP 65
LED Working Life-Span	>50000H
Certificate	CE , Rohs
Product Size	L600 x W280 x D120 mm
Net Weight / Gross Weight	6.00 kg / 6.50 kg

Advantages:

1. High power efficiency output, Non-image optics system

2. Luminaire efficiency up to 90 lm/W ± 3lm

3. Open air ventilation design, good heat dissipation function

4. energy-saving and srtong brightness

5. Superbright cool light output (no UV or heat energy)

6. Long service lifetime to 50000 hours

7. Easy to install and operate

8. No UV or IR radiation.

Notice:

1. Don't use in the place corrosive, flammable or explosive

2. Not install in the place near heat.

3. When the lamp lights, don't envisage it.
