Changzhou Xinsheng Electronics Co., Ltd.
China Manufacturer with main products: Optical Products, RF Connector |
Coarse Wavelength Division Multiplexer Module (CWDM)
| Supply Ability: | 1,000 Piece/Pieces per Month |
|---|---|
| Shipping: | 15 working days after receive the down payment |
| Payment Terms: | L/C, T/T |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | customize |
Specifications
Performance Specifications:
|
Parameter
|
MUX / DEMUX
|
||
|
4-Channel
|
|||
|
Operating Wavelength (nm)
|
1270~1610
|
||
|
Center Wavelength Accuracy (nm)
|
± 0.50
|
||
|
Channel Spacing (nm)
|
20
|
||
|
Channel Passband (@-0.5dB bandwidth (nm)
|
>0.25
|
||
|
Insertion Loss (dB)
|
≤ 1.5
|
||
|
Channel Uniformity (dB)
|
≤0.6
|
||
|
Channel Ripple (dB)
|
≤ 0.5
|
||
|
Isolation (dB)
|
Adjacent
|
≥30
|
|
|
Non-adjacent
|
≥40
|
||
|
Insertion Loss Temperature Sensitivity (dB/°C )
|
≤ 0.005
|
||
|
Wavelength Temperature Shifting (nm/ °C )
|
≤ 0.002
|
||
|
Polarization Dependent Loss (dB)
|
≤ 0.2
|
||
|
Polarization Mode Dispersion (ps)
|
≤ 0.2
|
||
|
Return Loss (dB)
|
≥50
|
||
|
Directivity (dB)
|
≥50
|
||
|
Max Power Handling (mW)
|
300
|
||
|
Operating Temperature (°C)
|
0 ~ +70
|
||
|
Storage Temperature (°C)
|
-40 ~ +85
|
||
|
Dimension (mm)
|
L120 x W80 x H11.6 or L100 X W80 X 10
|
||
|
Note: Connector losses are not included in the all insertion loses.
|
|||
