Specifications
| Parameter/Model | CUT40 | CUT60 | CUT80 | CUT100 | CUT160 |
| Input Voltage | AC220V±15% | AC380V±15% | AC380V±15% | AC380V±15% | AC380V±15% |
| Frequency | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Current | 30 | 12 | 18 | 23.1 | 44.3 |
| No-load Voltage | 230 | 295 | 268 | 268 | 320 |
| Output Current Range | 20-40 | 20-60 | 20-80 | 20-100 | 20-160 |
| Rated Output Voltage | 96 | 104 | 112 | 120 | 144 |
| Duty Cycle | 60 | 60 | 60 | 60 | 60 |
| No-load Loss | 40 | 60 | 60 | 80 | 100 |
| Efficiency | 80 | 85 | 85 | 85 | 85 |
| Power Factor | 0.73 | 0.93 | 0.93 | 0.93 | 0.93 |
| Insulation Grade | F | F | F | F | F |
| Housing Protection Grade | IP21 | IP21 | IP21 | IP21 | IP21 |
| Arcing Way | Contact | Contact | Contact | Contact | Contact |
| Recommened Air Pressure | 4-5 | 4-5 | 4.5-5.5 | 4.5-5.5 | 4.5-5.5 |
| Cutting Thickness | 1-16 | 1-25 | 1-25 | 1-40 | 1-16 |
| Net weight | 9 | 19 | 25 | 39 | 60 |
| Dimension | 371*153*232 | 480*204*303 | 515*263*372 | 560*370*350 | 670*337*617 |
1.Able to cut metal plates in various routes;
2.Outstanding cutting performance.Especially suitable for cutting carbon steel,stainless steel,aluminum and copper;
3.Widely used in iron structure construction,manufacture and automobile maintenance;
4.Improved cooling method for the cutting torch;greatly makes the cutting consumables more endurable;
5.Using air pressure adjusting equipment.Able to operate when the external air pressure is too high;
6.The cutting current is continuously adjustable.Direct and precise;
7.With protection of electro circuit against over current,over voltage and low-voltage.Safety in operation is assured.
