Specifications
Description Unit K90S
A B C
Shot volume cm3 120 163 212
Shot weight(PS) g(ps) 113 153 199
Oz 4 5.4 7
Screw diameter mm 30 35 40
Injection pressure Mpa 224 165 126
Screw I/D ratio L/D 23: 1 20.5: 1 18: 1
Screw stroke mm 170
Screw speed r/min 0-210
Clamping force KN 900
Opening stroke mm 320
Platen size mm×mm 540×540
Space between tie bars mm×mm 360×360
Max.daylight mm 680
Mold thickness (min-max) mm 130-360
Hydraulic ejection stroke mm 100
Hydraulic ejection force KN 28.5
Ejector pin 4+1
Hydraulic system pressure Mpa 14.5
Pump motor kw 8
Heating capacity kw 6.9
Number of temp control zones 4
Oil tank capacity L 144
Machine dimensions m × m × m
4.2×1.2×1.78
Machine weight kg 3000
Description Unit K120S
A B C
Shot volume cm3 182 238 301
Shot weight(PS) g(ps) 171 225 283
Oz 6 8 10
Screw diameter mm 35 40 45
Injection pressure Mpa 228 174 138
Screw I/D ratio L/D 23: 1 20.5: 1 18: 1
Screw stroke mm 190
Screw speed r/min 0-220
Clamping force KN 1200
Opening stroke mm 340
Platen size mm×mm 600×600
Space between tie bars mm×mm 410×410
Max.daylight mm 790
Mold thickness (min-max) mm 145-450
Hydraulic ejection stroke mm 100
Hydraulic ejection force KN 34.3
Ejector pin 4+1
Hydraulic system pressure Mpa 17.5
Pump motor kw 10
Heating capacity kw 8.9
Number of temp control zones 4
Oil tank capacity L 160
Machine dimensions m × m × m
4.3×1.2×1.8
Machine weight kg 3500
