(CE certificate)PET plastic bottles recycling machine
| FOB Price: | 50,000.00 - 200,000.00 USD/Set |
|---|---|
| Supply Ability: | 10 Set/Sets per Year |
| Shipping: | shanghai port |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | film whipping |
Specifications
PET bottle recycling machine
Feature:
1. High automation level, try best to reduce your cost on labor (especially for three shifts) and ensure high processing capacity: 300-2000kg/hr
2. Friendly control system (PLC integrated & separated control on each machine) and Touch screen panel, easy for operation, monitor and emergency stop.
3. All parts contacting with plastic material and water are made of high-quality 304 stainless steel; Ensure no second pollution to flakes.
4. Ideal impurity removal effect
The main parameter of the line:
|
1
|
Belt conveyor
|
1. Working length 5000mm
2. Conveyor material- PVC
|
|
2
|
Crusher
|
1. Model: HB-SWP720
2. Rotating blade-6 pieces
3. Fixed blade-6 pieces
4. Material of the cutter: D2
5. Crushing capacity- 600kg/h
6. Motor power- 37KW
7. Main shaft Speed-580rmp
8. diameter of sieve-14mm.
|
|
3
|
Screw loader
2 sets
|
1. Loading capacity-600kg/h
2. Motor power-3KW
3. stainless steel
thickness-4mm
|
|
4
|
Hot washer
|
1. Using steam heating method
2. Diameter of bucket-1300mm
Height: 3000mm
3. Two-layer design
4. Motor power -5.5KW
|
|
5
|
High-speed friction washer
|
1. Motor power -11KW
2. Adopting special design
3. Diameter of sieve-3mm
4. Main shaft speed-1000rpm
|
|
6
|
Poaching tank 2 sets
|
1. Motor power- 5.3Kw=(4+0.75+0.55)Kw
2 . Effective length- 5800mm
width-1000mm
3. Single-screw type
|
|
7
|
Horizontal dewatering machine
|
Motor power-7.5KW
High speed-1800rpm
Dewatering degree: 98%
|
|
8
|
separator
|
1. It can wipe off the film of PVC bottle flakes or gluewater. If you have this unit , can get 100% PVC bottle flakes
2. Part in contact with water is made of stainless steel
|
