Heat shrink end cap

Supply Ability:	1,000,000 Piece/Pieces per Month
Shipping:	within 7 days
Payment Terms:	L/C, T/T, Paypal, Western Union

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Sichuan in China
Packaging Details:	CTN

Specifications

heat shrinkable end caps are designed for the sealing and protection of both plastic and metal sheathed cables.

Dimension

Order Ref. Size	Length of Adhesive (I)	Length	Suitable for Cable Pairs
RSM(Q)-10/4	35±3	60±5	<50
RSM(Q)-18/6	35±3	65±5	≤50
RSM(Q)-20/8	35±3	65±5	≤50
RSM(Q)-25/8	35±3	65±5	≤50
RSM(Q)-30/12	45±3	95±5	50-150
RSM(Q)-40/15	45±3	95±5	150-300
RSM(Q)-56/20	55±5	130±5	200-600
RSM(Q)-66/25	55±5	130±5	200-600
RSM(Q)-78/30	70±5	150±5	600-1400
RSM(Q)-100/45	80±5	165±5	1600-2400
RSM(Q)-120/65	75±5	165±5	3200
RSM(Q)-140/65	75±5	165±5	3200
RSM(Q)-160/65	75±5	165±5	3200
RSM(Q)-180/90	75±5	170±5	Over 3200 pairs
RSM(Q)-200/90	75±5	170±5	Over 3200 pairs

*We can supplying special specifications according to the requirements of custom

Technical Data

Property	Test Procedure and Condition	Typical Performance
Radial change, %	130±2°C(1~3min)	≥50
Axial change, %	130±2°C(1~3min)	≤10
Shore Hardness, A		65-75
Tensile Strength, Mpa		≥13.0
Ultimate Elongation, %		≥400
Clod bend	-10±2°C/1hr	No Cracking
Volume Resistivity, Ω.cm		≥1.0×10¹³

Hot-melt Adhesive

Item	Unit	Typical Performance
Peel Off Strength	N/25mm	≥50
Cutting Strength	N/cm²	≥40
Soften Point	°C	80~90

Here's the list of other heat shrink products:
RSBA Heat-shrinkable closure for Pressurized cable jointing
RSBJT Heat-shrinkable closure for Under-ground with re-enterable filling compound
RSBJ Heat-shrinkable closure for Non-pressurized cable jointing
RSB Wraparound heat-shrinkable closure kit for Non-pressurized cable
RSBW Reinforced Heat-shrinkable cable repair sleeve
RSM Heat-shrinkable cable caps
RSY Round heat-shrinkable closure
Heat-shrinkable accessories

Welcome to contact us.
