Yongli Agro Machinery Co., Ltd.
China Manufacturer with main products: Pellet Mill, Feed Mill, Wood Chipper, Feed Plant, Pellet Production Line, Feed Machinery, Dryer, Mixer |
Wood chipper machine
| Supply Ability: | 10 Set/Sets per Month |
|---|---|
| Shipping: | 1 month |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
Specifications
YLBX Series Disc Chippers
Disc cutting machine is a production of refined wood chips special equipment is widely used in textile, paper, pulp, wood-based panel industries in the production process of the preparation section. It is divided into flat spiral disc and two disc types, and there is material on the material under the model. The main raw materials are cutting path after peeling wood, bamboo, wood slab and fuelwood harvesting times more than materials. However, too rough (more than feed more than size) too small (30mm or less) too short (250mm below) too thin (5mm or less) and irregular raw material (non-decomposing stump, branches, etc.) do not fully function with the uniform cutting.
Cutting range: logs, small wood, branches and twigs, planks, etc.
Features: Compact structure, easy operation and maintenance, high capacity. Raw materials are cut into high quality chips with even length, smooth chip cut and uniform chip thickness.
Main Parameters:
|
Model |
YLBX116A |
YLBX1710 |
YLBX1112 |
YLBX1112-1 |
YLBX1212A |
YLBX1216 |
YLBX1227 |
|
Knife disc diameter(mm) |
630 |
950 |
1220 |
1220 |
1220 |
1600 |
2650 |
|
Rotor speed(rpm) |
800 |
980 |
740 |
740 |
740 |
625 |
300 |
|
No. of knives(pcs) |
3 |
6 |
4 |
4 |
6 |
6 |
8 |
|
Clip length(mm) |
15-25 |
12-35 |
20-35 |
20-35 |
20-35 |
20-35 |
20-35 |
|
Type of feeding |
Horizontal |
Incline |
Horizontal |
Horizontal |
Incline |
Horizontal |
Horizontal |
|
Feed opening dimension(mm) |
130*150 |
207*190 |
400*275 |
400*275 |
300*300 |
545*383 |
584*560 |
|
Capacity(m3/h) |
2-3 |
5.5-8 |
15-20 |
15-20 |
15-20 |
25-45 |
100-130 |
|
Power of main motor(kw) |
22 |
55 |
110 |
110 |
110 |
220-250 |
2*280 |
|
Max. log diameter(mm) |
100 |
100 |
200 |
200 |
200 |
300 |
500 |
|
Type of discharge |
Upper |
Upper |
Upper |
Bottom |
Bottom |
Upper |
Bottom |
|
Total weight(kg) |
827 |
2665 |
4585 |
4256 |
4585 |
8732 |
32450 |
|
Overall dimension(mm) |
2340*1200*1845 |
2550*1600*1650 |
3000*1570*1614 |
3000*1400*1614 |
3100*1340*1714 |
3756*1855*2093 |
5745*4785*2845 |
|
Remarks |
Diesd engine |
Right feeding |
Right feeding |
Right feeding |
Right feeding |
Right feeding |
Right feeding |
