heat shrink sleeve(siliar to XAGA500)

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

RSBW Heat Shrink Wrap Aournd Sleeve, which is to XAGA500.

Adhesive lined, heat shrink wraparound sleeve that is closed with a flexible stainlesssteel locking channel. Used for general re-jacketing and sealing applications, protection of damaged cable or repair of cable joints. Installs easily in splice applications that are longer in length.

Features :

Made from thermally stabilised,cross linked polymeric material.
Shut down system not required for repair.
High Shrink ratio covers even irregular shapes.
Hot melt adhesive provides complete environmental sealing and insulation.
High resistance to UV rays,chemicals,corrosion,fungus etc.
Temperature sensitive paint changes colour when heat shrinking process is complete.

Applications:

Repair the outer / inner sheath damages on the cable.
Provides corrosion protection to the metallic parts of the cable that are exposed to polluted environments
Provides moisture proof protection to corrosion prone oil, water and gas pipelines.
Protection for Telecommunication cable joints.

heat shrink cable repair sleeve selection chart:

Model	Max. Inner Dia. Before Shrinkage	Min. Inner Dia. After Shrinkage	Application Range Diameter	Standard Full Length
RSBW 35-10	35	10	12-23	1m,1.4m
RSBW 50-15	50	15	17-30	1m,1.4m
RSBW 75-22	75	22	25-40	1m,1.4m
RSBW 105-30	105	30	35-55	1m,1.4m
RSBW 146-40	146	40	45-75	1m,1.4m
RSBW 180-50	180	50	62-95	1m,1.4m

These heat shrink wraparound sleeves can be customized, with or without valve. Welcome to inquiry us.
