Specifications

P16mm USA LED Sign
Technical Specifications
LED Lamp Parameters
No.	Item	Specifications
1	LED lamps	DIP546 , Oval
2	Wavelength	Red LEDs	620-630nm
		Green LEDs	520-535nm
		Blue LEDs	465-475nm
LED Module Specifications
1	Pixel Pitch	16mm
2	Pixel Configuration	2R1G1B
3	Module Resolution	16dots x 8dots
4	Module Size	256mm x 128mm
LED Cabinet Specifications ( Standard Cabinet )
1	Cabinet Size(WxHxD)	1024mm x 768mm x 175mm
2	Cabinet Resolution	64 x 48 pixel dots
3	Module Quanity	24 PCS
4	Cabinet Frame Material	black powder coated steel
5	Cabinet Weight	47Kg
Screen Parameters
1	Screen Resolution	3906 dots/㎡
2	Screen Brightness	9500 nits
3	Brightness Adjustment	manually or automatically
4	Driving Method	constant current static
5	View Angle	Horizontal 120° Vertical 60°
6	Optimum Viewing Distance	15m to 300m
7	Refreshing Frequency	≥180Hz
8	Input Voltage	AC220V/50Hz or AC110V/60Hz
9	Power Consumption	Max.: 1500W/㎡ Average: 500-1000W/㎡
10	Defects Rate	≤0.00001
11	MTBF	>5000 hours
12	Lifespan	≥100,000 hours
13	Protection Grade	IP65
