Three-dimensional Mixer

Payment Terms:	T/T

Inquiry Now

Related products from verified members

Dispersion Mixer

Price:

Min. Order:
QHS Series Beverage Drink Mixer

Price:78,945.00-93,630.00 USD/Set

Min. Order:1 Set
Plastic Granuals Mixer

Price:

Min. Order:1 Set
High Speed Hot and Cold Mixer

Price:6,000.00-17,000.00 USD/Set

Min. Order:1 Set
Two Dimensional Mixer for powder

Price:3,000.00-10,000.00 USD/Set

Min. Order:1 Set

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China

Specifications

Main usage

It's widely used in pharmaceutical, chemical, food and other industry on the try powder material mixing, rapid and uniform mixing of several materials at different specific gravities and different particle size.

Works principle

It makes the use of the unique three movement, pan rotate and rock principle, and generates a stream of powerful alternating pulse collapse of the movement, and then continuously promote the mixed material, which produces a vortex of change of energy gradients, which can produce excellent mixed effect. For the machine also has a smooth running, low noise, high load factor and short mixing time, etc

Features

The devices do not need make basis, it is easy installation and maintenance, with a long service life.

For the mixing effect is good, mixing time is short, mixing uniformity could be up to 99.5%;

Loading factor could be up to 85%, it is 2 times more than the ordinary rotary mixer.

Height is low, the rotation space is small, generally speaking, and the buildings do not need spring layer.

Eccentric design of the discharge side of the mixing barrel cone, discharge is no dead side, no residue, an easy clean, it is the GMP requirements.

RSH three-dimensional movement series mixer could be start at low speed, and running smoothly at the rated speed. Setting time, and then slow down to stop the machine. Automatic stopping position is the best location to discharge the materials.

Technical data:

Model	RSH-10	RSH-50	RSH-100	RSH-200	RSH-300	RSH-400
Full capacity (L)	10	50	100	200	300	400
Max load capacity (L)	8	40	75	160	240	320
Max load weight (kg)	8	40	75	160	240	320
Main speed (rpm)	0-15	0-15	0-15	0-15	0-15	0-15
Motor power (kw)	0.55	1.1	1.5	2.23	4	4
Dimensions cm	60x80x70	100x140x120	120x170x150	140x180x160	180x195x195	180x210x195
Weight (kg)	100	300	500	800	1000	1200
