Qinyang City Qinke Papermaking Machinery Co., Ltd.
China Manufacturer with main products: Fast Speed Toilet Paper Making Machine, Dryer Cylinder, Various Rolls for Paper Machine, 1575mm Toilet Paper Making Machine, Paper Napkin... |
1575mm toilet paper making machine
| FOB Price: | 50,000.00 - 200,000.00 USD/Piece |
|---|---|
| Supply Ability: | 50 Piece/Pieces per Year |
| Payment Terms: | L/C, T/T, D/P, Paypal, Western Union |
Related products from verified members
![5-Ply Complete Rigid Corrugated Cardboard Production Line[Corrugation Machine Price]](http://ic10.ecvv.com/upload/UserImage/20171118/200x200/357LayerComputerisedCardboardCorrugationMachineforSale_77fd46bc-3a58-48d5-bc8c-bad758f4306c.jpg)
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
Specifications
1575mm single-cylinder and single-wire paper machine
Technical data:
Adapt pulp: Waste, wood pulp.
Output paper: High & medium grade of toilet paper
Output weight: 14_30G/M2
Net width: 550mm
Wire width: 550mm
Capacity: 4-5T/D
Working speed: 150m/min
Rail gauge: 2400mm
Main frame of the equipment
Part name Equipment Specification Quantity
Mesh cylinder cylinder mould 1500mm x 1950mm 1
(stainless steel)
Sealed pressure vat 1
Couch press 450mm x 1950mm 1
Dryer part dryer can 2500mm x 1950mm 1
Touch roll 450mm x 1950mm 1
Winger roll 280mm x 1950mm 2
All the felt rolls
Winding part dryer cylinder 600mm x 1950mm 1
Equipped with the 250 speed reducer(1 set)
Drives and AV converter and adjustable speed transmission.
Control
All the accessory equipment
Number Equipment Quantity
(SET)
1 1575mm single-cylinder& 1 set
Single-wire toilet paper machine
2 Exhaust hood of the dryer can(double layers) 1 set
3 850 screw type ventilator 1 set
Sealed pressure vat 1 set
4 15 type roots pump 1 set
5 suction box 2 sets
5m3 high consistency hydrapulper 1 set
6 1.8m2 high frequency vibrating screen 1 set
7 35m3 bleacher machine 3 sets
380 double disks refiner 1 set
8 700 Thruster 3 sets
9 606 sand cleaner (6 PCS) 1group
Double head-box feed pump-100 6 sets
10 Double head-box feed pump-150 4 sets
11 Rewinding&embossing&perforated machine 1 set
Slitter 1 set
12 The whole set of work bench 1 set
13 2T boiler 1 set
All the accessary motors:
Number Electromotor Power Grade Quantity
(KW) (set)
1. First cylinder part 18.5 adjustable 1
2. Cooling cylinder 5.5 adjustable 1
3. Winding machine 4 4 1
4. Screw type ventilator 4 4 1
5. Vacuum pump 22 4 1
6. Hydrapulper 57 4 1
7. Vibrating screen 3 4 1
8. Bleacher 11 4 3
9. Washing drum 4 4 3
10 Double disks refiner 37 4 1
11.700 Thruster 11 6 3
12. Pulp pump 4 4 6
13. Pulp pump 7.5 4 4
14. Rewinding machine 3 adjustable 1
15. Slitter 3 4 1
16. Blower 7.5 4 1
17. Water supply pump 7.5 4 1
18. Induced draft fan 7.5 4 1
Technical data:
Adapt pulp: Waste, wood pulp.
Output paper: High & medium grade of toilet paper
Output weight: 14_30G/M2
Net width: 550mm
Wire width: 550mm
Capacity: 4-5T/D
Working speed: 150m/min
Rail gauge: 2400mm
Main frame of the equipment
Part name Equipment Specification Quantity
Mesh cylinder cylinder mould 1500mm x 1950mm 1
(stainless steel)
Sealed pressure vat 1
Couch press 450mm x 1950mm 1
Dryer part dryer can 2500mm x 1950mm 1
Touch roll 450mm x 1950mm 1
Winger roll 280mm x 1950mm 2
All the felt rolls
Winding part dryer cylinder 600mm x 1950mm 1
Equipped with the 250 speed reducer(1 set)
Drives and AV converter and adjustable speed transmission.
Control
All the accessory equipment
Number Equipment Quantity
(SET)
1 1575mm single-cylinder& 1 set
Single-wire toilet paper machine
2 Exhaust hood of the dryer can(double layers) 1 set
3 850 screw type ventilator 1 set
Sealed pressure vat 1 set
4 15 type roots pump 1 set
5 suction box 2 sets
5m3 high consistency hydrapulper 1 set
6 1.8m2 high frequency vibrating screen 1 set
7 35m3 bleacher machine 3 sets
380 double disks refiner 1 set
8 700 Thruster 3 sets
9 606 sand cleaner (6 PCS) 1group
Double head-box feed pump-100 6 sets
10 Double head-box feed pump-150 4 sets
11 Rewinding&embossing&perforated machine 1 set
Slitter 1 set
12 The whole set of work bench 1 set
13 2T boiler 1 set
All the accessary motors:
Number Electromotor Power Grade Quantity
(KW) (set)
1. First cylinder part 18.5 adjustable 1
2. Cooling cylinder 5.5 adjustable 1
3. Winding machine 4 4 1
4. Screw type ventilator 4 4 1
5. Vacuum pump 22 4 1
6. Hydrapulper 57 4 1
7. Vibrating screen 3 4 1
8. Bleacher 11 4 3
9. Washing drum 4 4 3
10 Double disks refiner 37 4 1
11.700 Thruster 11 6 3
12. Pulp pump 4 4 6
13. Pulp pump 7.5 4 4
14. Rewinding machine 3 adjustable 1
15. Slitter 3 4 1
16. Blower 7.5 4 1
17. Water supply pump 7.5 4 1
18. Induced draft fan 7.5 4 1
