fingerprint door lock

Biometric fingerprint door locks offer tremendous benefits compared to conventional keyed door locks, combination door lock or card reader door locks. Thus, biometric fingerprint door locks are superior for security protection, convenience, and speed.

The S520 series utilize high-speed CPU, advanced algorithm, unique sliding cover design, oversized LCD display and voice guide system creating a secure and completely user-friendly environment. The enrollment process is quick, effortless and no keys, codes or pin numbers.

Key advantages

The S520 offers a unique super-wide LCD display on the front lock body with multilanguage voice operation guide system, which is an unparalleled feature that truly achieve humanized design. Differs from common blue backlight display, SFG LCD is intelligent, more advanced and elegant. Moreover, the multilanguage voice system enable the interactive communication between human and locks.

The sliding front cover is another feature of SFG S520 Fingerprint door lock that not only allows protection for the optical sensor but also activates the fingerprint scanner when lifted and it can be accessed by fingerprint, passcode, or emergency mechanical key.

Powered by 4AA batteries, S520 is convenient to manager the fingerprints. You can enroll, look up, erase, clear, download, revise and specific rights control of all the fingerprints

Features

100% reliable-One Touch Instant Access

Fingerprint, password, or mechanical Key Override to access

Fashionable slide cover design

50 fingerprint users with two grades

Full digital LCD display user interface

optical nano meter surface plated sensor

Fingerprint scanner is made of extra hard glass to prevent scratches

Voice guide system for user friendly communication

Auto-lock when door close

Easy fingerprints management

Fits door thickness of 45-80mm

Easy installation on most standard doors

Optional Mortise for different application

Long battery life time: Exceed 4,500 times (4 x AA Batteries)

Low battery warning

1 YEAR Replacement warranty

Specification:

Item	Description
Model	S520 Series
Scanning time	<1 Sec
Verification time	<0.6 Sec
FRR(False Rejection Ratio)	0.1%
FAR(False Acceptance Ratio)	0.0001%
Static current	≤12MA, standby current <10μA
Dynamic current	110mA-180mA
Working pressure	DC 6V (4X1.5V alkaline batteries)
Operating temperature	-20℃~50℃
Operating humidity	10~92% RH
Resolution	500DPI
Identification Method	1: N; 1:1
Allowable rotation	360^.
Language	Chinese, English
Color available	Silver-red , silver-gray
Unlock access	fingerprint; password; emergency mechanical key
Fingerprint capacity	120 Fingerprints (5 for administrator, and 115 for guests)
Battery longevity	1 year
Measurement	316×68×36mm
