Specifications
Applications :
- These 75Ω coaxial cables are suitable for installation on board of ships and other indoor marine environments.
Standards :
-
IEC 60092-350 IEC 60332-3-22 IEC 60754-1,2 IEC 61034-1,2 NEK 606:2004
Construction :
- Conductors : 14AWG solid bare copper.
- Insulation : Foam PE.
- Shielding1 : Al/Polyester/Al tape.
- Shielding2 : Tinned copper braid.
- Bedding : Low smoke and halogen-free polyolefin, coloured black.
- Armour : Copper wire braid.
- Outer Sheath : Low smoke and halogen-free polyolefin.
Dimensions and Weight :
| Nominal Inner Conductor Diameter mm | Nominal Insulation Thickness mm | Nominal Sheath Thickness mm | Nominal Overall Diameter mm | Nominal Weight kg/km |
| 1.6 | 2.7 | 1.7 | 15.0 | 353 |
