Home >Products Catalog > AC/DC adapter > 5V 1A USB adapter USB charger with CE,UL,SAA,PSE FY0501000

5V 1A USB adapter USB charger with CE,UL,SAA,PSE FY0501000

FOB Price:	1.00 - 4.00 USD/Piece
Supply Ability:	1,000,000 Piece/Pieces per Month
Shipping:	FOB shenzhen, lead time:15-20 days
Payment Terms:	T/T, Western Union

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Overnight Battery Charger

Price:

Min. Order:1000 Pieces
LuguLake Ultra-Slim Qi-Enabled Wireless Chargin...

Price:19.99 USD/Piece

Min. Order:1 Piece

Product Details

Export Markets:	North America, South America, Southeast Asia, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	100pcs/ctn

Quick Details

Type: Electric
Use: Standard Battery
Model Number: FY0501000
Brand Name: fuyuang

Specifications

5V 1A USB adapter USB charger with CE,UL,SAA,PSE FY0501000

Specifications:
Input	100~240VAC 50~60Hz
	AC Plug: Eu,US, are available
Output	Plug: Standard is 5.52.1/5.52.5, Other size we will provide as your required
	Cable: 1.2M length
	Output voltage and power, details please see bottom model list
Packing	Product Dimension	803532mm
	White Box	100g/pc
Safefy and EMC	Safety standards EMC Emission EMC Immunity	UL60950,CSA C22.2, PSE/J60950,J55022,J3000. CE/EN55022,EN61000, FCC part 15 CB/IEC60950, CCC/GB4943, C-tick/N17653, V Eup class B EK KC/K60950,K00022,K00024 RoHS:EN2002/95-EC TUV GS/EN60950,EN60335,EN61558,EN62233.

Protection	Resistance Heat	when Tested within 10 minutes after product has been planced in a test chamber maintained at 105℃+/-3℃ for 16 hours. The product shall comply with the requirements of dielectric withstand test. Shall have insulation resistance not less than stated below as measured at 500VDC 10 MEGOHMS Minimum between the input and the output. Input and case together. 10 Megohms minimum.
	Inrush Current	Peak inrush current shall be limited 15A for a cold start
	Over currrent	Products include current fuse located within inut circuit
	Short Circuit	Capable of withstanding continuous short circuit and recover automatically
	Ripple and Noise	25~300mVp-p, 20MHz Bandwidth 10uF Ele. Cap.& 0.1uF Cer. Cap
Reliability	Electrostatic Discharge	At 150pF: 330Ω, for each point, 10 shots of direct discharge or air discharge. (1MΩ/SHOT), have no malfunction. Direct discharge: ±6kV, Air discharge: ±10kV
	Hi-Pot Test	5mA 3000VAC For 2 second between input and output,input and case. At an alternative potenials 5% higher may be applied for 1 second
	Leakage Current	0.25mA maximum, at nominal AC input voltage and frequency
	Temperature Rise	At 25℃ with the rated input 100-240Vac charged to the primary a rated load, on the secondary, every parts of the case surface rise 65℃ or less.
	MTBF	Life 30000 hours in full rated load and operation at 25 ℃
	Insulation Resistance	At 25°C after DC 500V 1min between input plug- DC plug, insulation resistance 100MΩ min)
Environment	Working Temp.	~29 ℃ + 45℃
	Working Humidity	20%-90% RH non-condensing
	Temp	~40 to +75℃ 10~95 RH
