Zhongyou Tongyong Luxi Natural Gas Equipment Co.,Ltd
China Manufacturer with main products: Cng Cylinder, Seamless Steel Cylinder, On-Board Cng Cylinder, Bi-Fuel Car Tank |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
10 Tubes CNG Trailer
Total cascade
Unit weight: 31800KG
Full-loaded weight: 4972KG
Total weight: 36772KG
Working pressure: 25MPa
Working temperature: -40℃~60℃
Filling medium: CNG (Compressed Natural Gas)
Testing pressure: 25MPa
Filling capacity: 6906Nm^3
Dimension: 12192x2438x1890MM
Cylinder
Cylinder quantity: 10PCS
Cylinder diameter: OD559mm
Working pressure: 25MPa
Testing pressure: 37.5MPa
Material: 4130X
Total water capacity: 22.1M^3
Water capacity: 2.210M^3
Working temperature: -40℃~60℃
ODxWTKxL: φ559x17.4x10950MM
Bursting discs
Burst pressure: 37.5MPa
Release-hole diameter: ≥φ20MM
Approvals: DOT AAA; ISO11120:1999; GB7258-2004 Motor Vehicle
Transportation Safety Conditions; JB4185-1986 General Technical
Requirements of Trailers; Q/ZYTY02-2010 Compressed Gas Tube Bundle
Container.
Features: Skid-mounted station as connection between monther filling station
and daughter filling station, loading capacity of CNG 6906M^3.
