Large Format Printer

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

Large Format Printer:

Crystaljet CJ3000 series large format printer(solvent printer,solvent plotter) information:

1.High-frequency servo motor system. With long life, high accuracy .And quick response

2.Single color positive flush, which save ink and reduces the cost of production

3.With over wide print platform design, the machine can load more heads and easy upgraded

4.Auto head protector keeps the printhead in a good condition

5.Auto front cover flip and sliding door design bring great convenience while operation

6.LED lighting system brings more convenience during printing and on printhead and printing status suspect

7.The Power of media adsorption can be adjusted which avoids printhead scratching with media

8.The value of advance step and bi-direction can be adjusted during printing

9.Printhead tenperature can be automatically detected by a device ,it will adjust the printhead voltage accordingly,which ensures printhead in a good performance

10.The wave and line eclosion function, solves the banding Problem perfectly

Bridge steel girder frame 1. Printer body features bridge steel girder frame: offers improved stability, durability and robustness.	Lightweight aluminum printer body 2. Wide pure aluminum printing platform: ensures precision, durability, support for moe print heads, protects against platform heat damage.
Strictly quality control system 3.Uses high-quality imported spare parts such as Panasonic servo motors, Hiwin rails etc.	Upgrade heating system 4.New pre-heating printing system ensures that print jobs are completed under consistent temperatures.
The user-friendly design 5.Convenient sliding door print cover design: convenient , provides more space for easy maintenance;	Automatic moisturizing system 6.Automatic moisturizing system: keeps print heads clear and protects them while the printer is not in use.
Automatic moisturizing system 7. Excellent PC stand design: facilitates easy operation.	Full automatic flex feeding system 8. Micro computer control, flex movement could be detected manually or automaticly by infrared.

Specification:

Model		CJ-F3304SPT510	CJ-F3308SPT510
Printhead		Seiko SPT Printhead 255_35pl
No of Printheads		4PS	8PS
Printhead Sequency		1×4	2×4
Print Width		3200mm 125.9inch
Media Width		3300mm 1259.9inch
Media		Flex,PVC Vinyle,One way vision,Mesh ect
Print speed	Print mode	Speed	Speed
	High speed	240×540 3pass 52m²/h	240×540 3pass 104m²/h
	Middle speed	240×720 4pass 39m²/h	240×720 4pass 78m²/h
	Middle speed	360×540 3pass 36m²/h	240×540 3pass 72m²/h
	Standard speed	360×720 4pass 26m²/h	360×720 4pass 52m²/h
Ink Type	Ink Type	Solvent ink
	Color	C\M\Y\K	C\M\Y\K
Ink supply system		Continuously Ink Supply System
Cleaning method		Automatic positive cleaning system(with pressure protection)
RIP software		PhotoPrint,Main Top,UltraPrint
Interface		USB2.0
Printing assistant system	Auto feeding system	Standard
	Heating system	Standard(Front heater,Rear heater,Fan)
	clipper	Standard
Printer info	Power	AC220V 50/60HZ
	Working environment	Temperature 20^oC--28^oC, Humidity 40%--70%
	Machine size and weight	5160mm×830mm×1070mm 350kg
	Shipping size and weight	5300mm×1020mm×1240mm 500kg
