Anhui Safe Electronics Co., Ltd.
China Manufacturer with main products: Capacitor, Film Capacitor, Inverter Welding Machine Capacitor, Resonant Capacitor |
Air conditioner capacitor CBB65 with CE,CQC Approval
| FOB Price: | 0.10 - 5.00 USD/Piece |
|---|---|
| Supply Ability: | 10,000 Piece/Pieces per Day |
| Shipping: | Sea, air, etc. |
| Payment Terms: | L/C, T/T, Western Union |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Anhui in China |
| Packaging Details: | Standard Package for professional capacitor |
Specifications
Capacitor CBB66/CBB65/CBB60/CBB61 AC metallized polypropylene film Capacitor
Feature:
The product is equipped inside with reliable explosion-proof equipment and is highly safe. With its good self-healing characteristic and long life-span, it is widely used for air-conditioners, refrigerators, generators, compressor, etc..
The product is equipped inside with reliable explosion-proof equipment and is highly safe. With its good self-healing characteristic and long life-span, it is widely used for air-conditioners, refrigerators, generators, compressor, etc..
Specification:
Working Temperature Range climate types: 40/70/21
Rated Voltage Range :110Vac,250Vac, 300Vac, 370Vac, 440Vac ,450vac,480vac,500vac,550vac,600vac,630vac
Rated Capacitance Range 0.7-120uF
Dissipation Factor Tan ≤ 0.002 (50Hz)
Rated Tolerance of capacitance 5% 10%
Testing Voltage between leading-out ends: 1.75UR 10S no break down
Insulation resistance between leading-out ends: 3000
Dimensional specification (mm):
|
Rated voltage(VAC) |
Nominal capacitance(μF) |
Size(mm)
|
|
|
D
|
H
|
||
|
200,250,370,
400,440,450,480,550,630
|
3,4,5,7.5,10,12.5,15,17,20,22.5,
25,30,35,40,45,50,55,60,70,80,100,
25+5, 30+5, 35+5, 50+5, 60+5, 70+5, 80+5…
|
40,45,50,55,
60,63.5,
52*32,71*45
|
60,65,70,75,80,85,90,95,100,105,110,115,
120,125,135,138
|
|
Product type
|
AC motor capacitor
|
|
Capacitance range
|
1uF~120uF
|
|
Capacitance deviation
|
±5% or according to customers’ requests.
|
|
Rated Voltage
|
250VAC,370VAC,400VAC,450VAC,500VAC,550VAC,600VAC
|
|
Rated frequency
|
50/60Hz
|
|
Operating Temperature
|
-40°C~+85°C
|
|
Class of safety protection
|
P1, P2
|
|
Testing voltage
|
T-T:2.0Un/60S
|
|
Insulation resistance
|
>=3000s
|
|
Tangent of loss angle of a capacitor
|
tanσ≤0.002 (100Hz)
|
|
Life expectancy
|
Class A,Class B, Class C |
|
Size
|
according to chart or users require
|
Note: Other specifications and sizes out of the table are negotiable. For more details,pls feel free to contact us at any time!
