NANJING ROADSKY TRAFFIC FACILITY CO., LTD.
China Manufacturer with main products: guardrail post driver, guardrail pile driver, guard rails, W beam guardrails, tandem vibratory roller, hand plate compactor, cable drilling... |
Reversible Vibratory Plate Compactor
| FOB Price: | 1,000.00 - 2,500.00 USD/Set |
|---|---|
| Supply Ability: | 100 Set/Sets per Month |
| Shipping: | 10days after receiving advance payment FOB QINGDAO |
| Payment Terms: | T/T |
Related products from verified members
| Export Markets: | South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | Export and sea-worthy standard special packing |
Specifications
Reversible Vibratory Plate Compactor
Application
Application
Hydraulic Reversible Vibrating Plate Compactor is with high centrifugal force, low barycenter, comfortable operation, is widely used to tamper engineering foundation, road margin and asphalt surface on constructing road, street, building, ditch and bridge in the field of road, municipal engineering, construction and water conservancy etc. It is better used tamping of narrow laneway.
Main Features
1. Infinitely variable hydraulic forward and reserves motion, as well as on-spot-compaction
2. Heavy-duty shock mounts reduces vibration to the upper engine and handle.
3. Soft materials on the handle for convenient handling and operation
4. Centrally-located bar and compact design make it use in trenches and other restricted space easily.
5. Wear-resistant base plates extent life, impact-resistant and open self cleaning base plate.
6. Wrap around protection frame protects the compactor from accidental job-site damage.
7. Hydraulic adjustment control lever for easy direction change
8. Reverse travel safety protection ensure the plate automatically reverts to slow forward travel if the operator releases the travel control lever while reversing.
Main Technical Specification
|
Parameter
|
Unit
|
RS-13B
|
RS-14B
|
|
Total Weight
|
kg
|
265
|
285
|
|
Overall Dimension (L*W*H)
|
mm
|
1280*480*1020
|
1380*500*1020
|
|
Plate Size
|
mm
|
700*420
|
700*500
|
|
Compacting Area
|
m2/h
|
680
|
750
|
|
Vibration Frequency
|
HZ
|
68
|
68
|
|
Moving Speed (Forward/Backward)
|
m/min.
|
21
|
21
|
|
Centrifugal Force
|
KN
|
40
|
50
|
|
Nominal amplitude
|
mm
|
0.5
|
0.5
|
|
Grade Ability
|
°
|
25°
|
25°
|
|
Compacting Depth
|
Soil (cm)
|
25
|
25
|
|
Asphalt (cm)
|
20
|
20
|
|
|
Type of Engine
|
|
Honda G×270 Gasoline Engine or Changzhou 186 Diesel Engine
|
Honda G×270 Gasoline Engine or Changzhou 186 Diesel Engine
|
|
Power
|
KW
|
7.5
|
7.5
|
|
Rotational Speed of Engine
|
rpm
|
3600
|
3600
|
|
Fuel Tank Capacity
|
L
|
6
|
6
|
|
Fuel Consumption
|
L/h
|
1.1
|
1.2
|
