Specifications
Roll Forming Machine For Tubeless Steel Rims
Main function
Rolling curved shape machines is the important machines which are used to form the wheel rims curved surface. Usually it is combination used with three lathe, they are sketchy rolling, medium rolling and precise rolling. After the processing, it may obtain the ideal curved surface and quality surface.
Rolling curved shape machines is the important machines which are used to form the wheel rims curved surface. Usually it is combination used with three lathe, they are sketchy rolling, medium rolling and precise rolling. After the processing, it may obtain the ideal curved surface and quality surface.
Main features
The main axle uses high quality alloy steel products that are go through strict heat treatment. Strict control stress corner, increase bending strength. The wheel rims semi-manufactured goods entire process completes automatically, including feed in, rolling, withdrawal. The main axle rotational speed may be change stepless according to the craft need.
|
Machine size |
W*L*H 1560*3057*2500 |
|
Base size |
W*L 1560*1390 |
|
Main axle pattern diameter |
Φ200 |
|
Up and down axis center distance |
340~480 |
|
Lower axle vertical traveling range |
240 |
|
Largest diameter of wheel rims |
950(28”) |
|
Main axle pattern length |
500mm |
|
Main axle rotational speed |
2~200r/min |
|
Main axle torque |
4807NM |
|
Idler wheel feed in force |
400KN |
|
Rolling steel plate thickness |
7~10 |
|
System fixed cylinder pressure |
20MP |
|
Electric motor power |
55+55+7.5+1.1=118.6KW |
|
Work table travel range |
1000mm |
|
Machine gross weight |
11T |
