well drilling TCI single cone bits

Inquiry Now

Related products from verified members

Fishing ice auger drill bit

Price:

Min. Order:100 Pieces
Tungsten Carbide Inserts for Rotary Drilling Bi...

Price:40.00-50.00 USD/Kilogram

Min. Order:30 Kilogram
diamond tools/cutting tools: diamond core drill...

Price:

Min. Order:

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Specifications

1. Advantages of our products:

(1) Bits sizes range from 3 7/8” to 26

(2) Covers almost all IADC codes

(3) suitable for sidetracking, deep well drilling and old well repair

(4) drilling formation:medium to hard

(5) antiwear and long lifetime

(6)stocks adequate, time delivery

(7) rich experience in drill bit

(8) good after-sales service

(9) High quality, competitive price

2.The design of the product structure:

(1)Cutting structure:

In response to the characteristics that inserts in different areas on the cone have different

cutting actions, conical inserts are placed in permanent contact area and wedge inserts are

placed in alternative contact area so that the drilling efficiency is greatly improved. Wear

resistance of cutting structure is enhanced by setting diamond inserts in the permanent

contact area of the cone Where inserts are severely worn. Tungsten carbide inserts are

placed on cone top face to protect cone body from abrasive erosion.

(2) Gauge Structure:

With active cutting gauge protection inserts on bit body, the bit has good gauge protection

inserts on bit body, the bit has good gauge protection and up drill capability

(3) Bearing Structure:

High precision journal bearing, Ball lock the cone. Hardface heard bearing surface. Cone

bearing inlaid with friction reducing alloy. Abrasion resistance and seizure resistance of the

bearing are improved. Compared with three cone bit, the leg bearing is bigger, so it can

receive higher WOB and high reliability.

(4) Hydraulic Design:

Small angled water course design increased the shirttail thickness and can effectively

prevent the watercourse erosion. Optimized hydraulics structure improves the clearing

capability and increases ROP.

3. Product Application:

It is suitable for sidetracking, deep well drilling and old well repairing.

4. Cutting structure

In response to the characteristics that inserts in different areas on the cone have different cutting

actions, conical inserts are placed in permanent contact area and wedge inserts are placed in

alternative contact area so that the drilling efficiency is greatly improved. Wear resistance of cutting

structure is enhanced by setting diamond inserts in the permanent contact area of the cone where

inserts are severely worn. Tungsten carbide inserts are placed on cone top face to protect cone

body from abrasive erosion.

5. Gauge Structure

With active cutting gauge protection inserts on bit body, the bit has good gauge protection inserts

on bit body, the bit has good gauge protection and up drill capability

6. Bearing Structure

High precision journal bearing, Ball lock the cone. Hardface heard bearing surface. Cone bearing

inlaid with friction reducing alloy. Abrasion resistance and seizure resistance of the bearing are improved. Compared

with three cone bit, the leg bearing is bigger, so it can receive higher WOB and high reliability.

7. Hydraulic Design

Small angled water course design increased the shirttail thickness and can effectively prevent the
watercourse erosion. Optirnized hydraulics structure improves the clearing capability and increases ROP.

8. Product Application

It is suitable for sidetracking, deep well drilling and old well repairing.

size		Bit Type
In.	mm	Bit Type
4 1/8	104.8	517, 527, 537, 617
4 1/2	114.3	517, 527, 537, 617
4 5/8	117.5	517, 527, 537, 617
4 3/4	120.6	517, 527, 537, 617
5 7/8	149.2	517, 527, 537, 617
6	152.4	517
