Qingdao Cimc Special Vehicles Co., Ltd.
China Manufacturer with main products: Trailer, Semi-Trailer, Special Vehicle, Semitrailer |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|
Specifications
1) Dimensions and weight:
A) Nominal dimensions (L x W x H): 14, 150 x 2, 740 x 1, 600mm.
B) King pin height: 1, 100mm c) King pin setting: 1, 100mm from rear face of front bolster
D) Max. Payload: 57, 000kg e) Tare weight: 7, 000kg± 2%
2) Running system:
A) Suspension system: Any kind
B) Axle: Various axles like BPW, YORK and FUWA with various bearings
D) Tire: Various brands of bias tires or radial tires
E) King pin: Forged steel, 2" or 3.5", welded or bolt-in
F) Landing gear: 24T, 25T
3) Chassis:
A) Heavy duty construction
B) Main beam: High-tensile steel
C) Surface preparation: Shot blast
E) Painting: Zinc-rich primer and modified urethane topcoat as customers' choices
4) Brake system:
A) Optional double line air brake system with single air tank, standard connectors on front bolster
B) Optional anti-lock brake system are available
5) Electrical system: Standard electrical equipment
Features:
1) Heavy duty construction
2) All major structural steel parts of high-tensile steel
3) Entire chassis shot-blasted.
4) Paint system comprising zinc rich primer and urethane topcoat paint.
A) Nominal dimensions (L x W x H): 14, 150 x 2, 740 x 1, 600mm.
B) King pin height: 1, 100mm c) King pin setting: 1, 100mm from rear face of front bolster
D) Max. Payload: 57, 000kg e) Tare weight: 7, 000kg± 2%
2) Running system:
A) Suspension system: Any kind
B) Axle: Various axles like BPW, YORK and FUWA with various bearings
D) Tire: Various brands of bias tires or radial tires
E) King pin: Forged steel, 2" or 3.5", welded or bolt-in
F) Landing gear: 24T, 25T
3) Chassis:
A) Heavy duty construction
B) Main beam: High-tensile steel
C) Surface preparation: Shot blast
E) Painting: Zinc-rich primer and modified urethane topcoat as customers' choices
4) Brake system:
A) Optional double line air brake system with single air tank, standard connectors on front bolster
B) Optional anti-lock brake system are available
5) Electrical system: Standard electrical equipment
Features:
1) Heavy duty construction
2) All major structural steel parts of high-tensile steel
3) Entire chassis shot-blasted.
4) Paint system comprising zinc rich primer and urethane topcoat paint.
