Hangzhou Akplas Machinery Co., Ltd.

[ Zhejiang, China ]
Business Type: Manufacturer
Brand(s): AKPLAS
Main Markets: North America, Southeast Asia, Africa, Mid East
Main Product: Plastic Injection Molding Machine, Bakelite Plastic Injection Molding Machine, Vertical Injection Molding Machine, Plastic Moulding Machine
Year Established: 2007
Legal Representative: Bread
Factory Location: Changle Industrial Development Zone, Jingshan Town, Yuhang District, Hangzhou, Zhejiang China
Years OEM Experience: 10
Employ Number: 101 - 500 People
Factory Size: 5,000-10,000 square meters
Number of R&D Staff: 5 - 10 People
Number of QC Staff: 5 - 10 People
  • Onsite operations checked and legal status confirmed
Ecvv Trade
Hangzhou Akplas Machinery Co., Ltd.

China Manufacturer with main products: Plastic Injection Molding Machine, Bakelite Plastic Injection Molding Machine, Vertical Injection Molding Machine, Plastic Moulding Machine

Home  >Products Catalog > AK > Injection Molding Machine AK-DS-Series

Injection Molding Machine AK-DS-Series


Related products from verified members

Quick Details

  • After-sales Service Provided: Overseas service center available
  • Clamping Force: 150T
  • Brand Name: AKPLAS
  • Style: Vertical
  • Condition: New
  • Certification: CE,GB/T19001
  • Opening Stroke: 350MM
  • Injection Rate: 141-171cm3/sec
  • Automatic: Yes
  • Model Number: AK-DS-Series

Specifications



Company Profile
Special Machine for Auto Sealing Rubber Strips
AKPLAS specializes in manufacturing vertical injection molding machines. the company accumulates exclusive technology and R&D capability over years. We have CE certification, passed GB/T19001-2008idtISO9001:2008,
Credit dun &bradstreet China risk assessment level.
Today, AKPLAS has 100  kinds of molding machines with 25-650T clamping force and 1-6000g shot weight in at, AC, AK three series. Annual production is more than 1200 sets. the advantage of AKPLAS is creating special machines to meet customers' demands.
Special Machine for Auto Sealing Rubber Strips
Today, by adopting technology from Europe and Japan, AKPLAS has superior technology and most various machine types in domestic. the quality of our machines have reach the internationally advanced level.
Special Machine for Auto Sealing Rubber Strips

There have  20 Home offices  Inland of China.
 Special Machine for Auto Sealing Rubber Strips
Foreign  agency 12 offices.

Service Promise
Special Machine for Auto Sealing Rubber Strips

1) Debugging, including adjustment and technological process for advice,help to produce qualified products;
2) Employee training, we send engineer to your company for explain in detail:
  mechanical structure                                hydraulic system                                                                           Electric control system                              plastic technology
to help your operator to master the machine performance, be familiar with the operation and can produce qualified Products, daily maintenance, and your company can send staff to our factory for study.

 We design and manufacture various machine type in accordance with the customers' requirements.

You can trust us, we will provide entire technical support in pre-sale, sale and after-sale.


SPECIFICATIONS

Clamping force 90T-650T
Injection quantity  100g-6000g

Model
Units
AK-1500DS
Injection System
Screw Diamater
mm
50
55
Injection Pressure
Kg/cm2
1856
1534
Theoretical Shot volume
cm3
471
570
Max.Shot Weight (P.S)
g/Oz
420/14.8
509/17.9
Injection Rate
Cm3/sec
141
171
Temperature Control
ZONE
4
Material Hopper Capacity
L
60
Clamping System
Clamping Force
T
150
Opening Force
T
7.25
Distance between Tie Bars
mm
600460
the Biggest Mold Contain Space
mm
580450
Min. Mold Height
mm
250
Opening Stroke
mm
350
Max.Open Daylight
mm
600
Ejector Force
T
5.4
Ejector Stroke
mm
115
Sliding form system
Sliding Platen Size
mm
1250593
Sliding Platen Stroke
mm
620
Round set Diameter
mm
Hydraulic Electric System
Max.Hydraulic Pressure
Kg/cm2
140
Pump Output
L
480
Pump Motor Power
Kw
18.5
Barrel Heating Power
Kw
7
Total Wattage
Kw
25.5
Others
Machine Weight
T
6.2
Machine Dimension(LXWXH)
m
3.22.22.9
