LSY series Screw Conveyor
| FOB Price: | 1.00 - 1,000.00 USD/Set |
|---|---|
| Supply Ability: | 10,000 Set/Sets per Month |
| Shipping: | 30 days after deposit |
| Payment Terms: | L/C, T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Henan in China |
| Packaging Details: | standard package |
Specifications
Detailed Product Description
1.High conveying capacity
2.Small size and rapid rotary speed
3.Good sealing quality and rigidity
Detailed Product Description
Screw Conveyor:
1.High conveying capacity
2.Small size and rapid rotary speed
3.Good sealing quality and rigidity
1.High conveying capacity
2.Small size and rapid rotary speed
3.Good sealing quality and rigidity
Screw Conveyor
Introduction of screw conveyor:
The modular LS Screw Conveyor system is highly versatile offering numerous solutions for conveying powdery or granular materials. LS Screw Conveyors are manufactured in carbon steel with a suitable surface finishing. They are made up from a tubular trough that is equipped with at least one inlet and outlet spout, a welded flange at each tube end, helicoid screw flighting welded on a centre pipe with a coupling bush at each end, two end bearing assemblies complete with self-adjusting shaft sealing unit, a number of intermediate hanger bearings depending on the overall length of the screw conveyor. Furthermore, LS Screw Conveyors are equipped with a gear motor that suits the application
Features:
1. High conveying capacity, safe and reliable operation.
2. Good adaptability and long service life.
3. Small size and rapid rotary speed, which ensures rapid and average conveying.
4. Good sealing quality and rigidity. The outer casing is made of seamless steel pipes, and the end caps are connected with flanges.
Advantages:
Compares with other equipments, screw conveyor has advantages of small dimension of section of full machine, good seal capability, balanced and credible running, multipoint loading & unloading, safety operating and simply maintenance etc.
Application of screw connveyor:
1. Screw conveyors are widely used in various industries such as building
materials, chemicals, power, metallurgy, coal carbon, food and other
industries, horizontal or inclined conveyor for powder, granular and
small-block materials, such as coal, ash, slag, cement, food and so on,
2.The material temperature is less than 200 °C.
3.Screw conveyor is not suitable for perishable, viscous, easy caking
materials.In the concrete mixing station, the conveyor's role has been the
largest expression.
Main technical parameters:
| Model Item | LSY160 | LSY200 | LSY250 | LSY300 |
| The Diameter of Screw Body(mm) | 160 | 193 | 250 | 300 |
| Conveyance Distance(m) | 2.5--6 | 4.5--12 | 6--9 | 6--9 |
| Speed of Screw Body (r/min) | 100 | 209 | 209 | 174 |
| Diameter of Outer Shell(mm) | Æ194 | Æ219 | Æ273 | Æ325 |
| Working Angle | ≤20° | ≤45° | ≤45° | ≤45° |
| Conveyance Capacity(t/h) | 25 | 35 | 50 | 75 |
| Motor Model | Y100L-4 | Y132M-4 | Y160M-4 | Y180M-4 |
| Motor(kw) | 3--7.5 | 4--11 | 7.5--11 | 11--18.5 |
