Shanghai Vulcan Machinery Co., Ltd.
China Manufacturer with main products: Machine Tools, Lathe, Milling Machine, Drilling Machine, Grriding Machine, Metal Forming Machine, Metal Bending Machine, EDM Machine |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
Specifications
Gear Head Auto-Feed Drilling Machine
Specifications:
Specifications:
| Model |
ZS-40A / ZS-40AP
|
ZS-40AHS / ZS-40APS
|
| Max. Drilling capacity (mm) |
40
|
40
|
| Max. Tapping capacity (mm) |
Cast Iron: M32 Steel: M24
|
Cast Iron: M32 Steel: M24
|
| Diameter of column (mm) |
115
|
115
|
| Spindle travel (mm) |
110
|
110
|
| Distance spindle axis to column generating line (mm) |
261.5
|
261.5
|
| Max. Distance spindle nose to table (mm) |
/
|
745
|
| Max. Distance spindle nose to table (mm) |
800
|
1245
|
| Spindle taper |
MT4orR8
|
MT4orR8
|
| Spindle speeds range (r/min) |
50-1250
|
20-1250
|
| Spindle speeds series |
6
|
6
|
| Spindle feeds |
0.12 0.18 0.25
|
0.12 0.18 0.25
|
| Dimension of worktable surface |
/
|
570× 470
|
| Table travel (mm) |
/
|
515
|
| Dimension of base (mm) |
635× 460/690× 520
|
635× 460/690× 520
|
| Overall height (mm) |
1400/1450
|
1760/1810
|
| Main motor (W) |
750 or 1100
|
750 or 1100
|
| Coolant motor (W) |
-/40
|
-/40
|
| G. W/N. W (kg) |
300/260 360/320
|
360/320 390/350
|
| Packing dimension (cm) |
75× 58× 150/75× 58× 156
|
82× 73× 186/87× 73× 191
|
