Shanghai Haibar Mechanical Engineering Co., Ltd.
China Manufacturer with main products: Belt Filter Press, Water Treatment, Polymer Preparation Unit, Sewage Dewatering Equipment, Belt Filter, Filter Press, Effluent Treatment... |
Water Filter for Industrial Effluent Treatment Plant HTB3 Series
| FOB Price: | 28,880.00 - 75,800.00 USD/Set |
|---|---|
| Supply Ability: | 300 Set/Sets per Year |
| Shipping: | 6weeks after receiving deposit |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shanghai in China |
| Packaging Details: | wooden packaging |
Specifications
Water Filter for Industrial Effluent Treatment Plant HTB3 Series
known as Belt Filter Press or Belt Press is the most versatile solution for sludge dewatering in small and middle size sewage treatment plants. It is specially designed for sludge with very low solid content (0.4% - 1.5%). HTB3 has the best ratio of performance/price, and is widely used for sludge dewatering in chemical, mining, paper, textile, electronics, municipal, and other industries.
Generally, the sludge from a sewage treatment plants is dewatered as following processing:
Sludge with a solid content of 0.5% - 5% will first be flocculated by the flocculation unit, and pre-dewatered by the sludge thickener to reduce about 90% volume to achieve a solid content usually 3% - 9%, and further dried by the belt filter press to achieve the final solid content about 15% - 40%.
Specifications of HTB3:
|
HTB3-750L
|
HTB3-1000L
|
HTB3-1250L
|
HTB3-1500L
|
HTB3-1750
|
HTB3-2000
|
||
|
Belt Width (mm)
|
750
|
1000
|
1250
|
1500
|
1750
|
2000
|
|
|
Low consistency
(S.S 0.4%-0.8%)
|
Treating capacity (m3/hr)
|
9.9~18
|
14.2~25
|
22~32
|
23.8~40
|
28.5~50
|
33~60
|
|
Dried Sludge (kg/hr)
|
42~99
|
60~132
|
84~186
|
100~215
|
120~250
|
140~310
|
|
|
Middle consistency
(S.S 0.8%-1.5%)
|
Treating capacity (m3/hr)
|
8.8~11.5
|
11.8~17
|
16.5~23.0
|
19~27.5
|
23~35
|
29~40
|
|
Dried Sludge (kg/hr)
|
76~146
|
100~195
|
140~270
|
160~310
|
196~380
|
240~520
|
|
|
Water content rate (%)
|
65~84
|
65~84
|
65~84
|
65~84
|
65~84
|
65~84
|
|
|
Power consumption
(HP)
|
Driving motor
|
1/2
|
1/2
|
1/2
|
1
|
1
|
1
|
|
Agitating motor
|
1/4
|
1/4
|
1/2
|
1/2
|
1/2
|
3/4
|
|
|
Drum Thickener
|
1/2
|
1/2
|
1/2
|
1/2
|
1
|
1
|
|
|
Dimensions (mm)
|
Length
|
4850
|
4950
|
5200
|
5200
|
5400
|
5400
|
|
Width
|
1400
|
1650
|
1900
|
2150
|
2400
|
2650
|
|
|
Height
|
2750
|
2800
|
2800
|
2850
|
2900
|
2900
|
|
|
Reference Weight (kg)
|
1600
|
1830
|
2050
|
2380
|
2800
|
4300
|
|
Advantages of HTB3:
1. Robust construction built by stainless steel SUS304 or SUS316
2. Specially suitable for light sludge with solid content from 0.4% to 1.5%
3. Variable belt speed available (1 - 7 m/min)
4. Continuous operation with low maintenance
5. Belt cleaning with stainless steel spray tubes with nozzles
6. Automatic belt tracking/tensioning during operation
7. Compact design to save your limited space
