solventless laminator

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China

Specifications

solventless lamaintor / solventfree coating machine

MainFeatures:

1.The first unwinding

1) Single station unwinding , it is by 20kg magnetic powder brake to control the unwidning tension’s steady

2)Loading device is 3 inches air shaft ( inner diamter of paper tube )

3)Max.diameter of unwinding: Φ1000mm

2.Rewinding device

1) Single station rewinding, rweinding is by servo motor drive to control the rewinding tension’s steady

2) Loading device is 3 inches air shaft ( inner diameter of paper tube )

3) Max.diameter of rewinding: Φ1000mm

4) Rewinding tension automatic control device: It will achieve automatic control by ultrasonic wave sensor and

magnetic powder brake as different diameter ,for keep rewinding tension’s steady

5)Tenxion taper range: 50---100%

6)This machine has pneumatic rewinding pressure roller device to ensure the rewinding tightness

3.Main Technology Parameters:

1.Coating type : Four Roller Coating

2.Machine Speed: 350m/min

4.Coating Width: 600～1300mm

5.Coating weight: 0.5～5g/m2

6.Max Unwding Diameter: 1000mm

7.Max Rewinding Diameter: 1000mm

8.Heating Temperature: 0～95℃

9. Power: about 45kw

10.Power Supply: 380V 50Hz(Provided by customer)

11.Air Supply: 0.6～0.8MPa(Provided by customer r)

12.Water Source: 0.2～0.4MPa circulating water(Provided by customer)

13.Synchro Tracing glue content and main speed , it also can be controlled independently .
