Fe3O4 Iron Ore Wet Type Beneficiation Plant

Specifications

Fe3O4 means magnetic iron ore, the beneficiation plant is wet type. The main equipment include stone crushers,feeder,ball mill,two stage of wet magnetic separating process,etc.

Fe3O4 Iron Ore Wet Type Beneficiation Plant process flow:
The specific Magnetic Separating Process is as follows: The extracted ore should be crushed by jaw crusher initially. When it gets the reasonable fineness, it is transported into ball mill by electromagnetic feeder, and grinding by ball mill. The subtle milled ore gets the next procedure: classification. There is a theory that if the weights of solid particles are different, the sedimentations will be different, and the mixed ore can be classified by screw classifier. The classified ore gets into magnetic separator. Since the specific magnetization coefficients of ores are different, the magnetic substance of mixed ore is separated from others with magnetic and mechanical force.
Since the separated ore are wet, they should be dewatered by thickner initially, and dried by dryer.

wet magnetic separator features:
1)large capacity:10-280t/h
2)applicable to ore dressing
3high magnet intensity:100-600mt
