Favourable Coaster Type Mini Bus With 19-33 Seats
| FOB Price: | 16,000.00 - 20,000.00 USD/Set |
|---|---|
| Supply Ability: | 500 Set/Sets per Month |
| Shipping: | Within 45 days after deposite |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | Southeast Asia, Africa, Mid East, Eastern Asia |
|---|---|
| Place of Origin: | Shandong in China |
| Packaging Details: | package as required |
Quick Details
- Seats: 21 - 40
- Emission Standard: Euro 3
- Transmission Type: Manual
- Max Speed: 91 - 110 km/h
- Steering Position: LHD
- Fuel Type: Diesel
- Dimensions (L x W x H) (mm): 7000*2040*2650
- Brand Name: chunchou
- Model Number: jnr6601
- Engine model: CY4102BZLQ
- Max. power (Hp/rpm): 120 Hp/2800rpm
- Max. torque (Nm/rpm): 343/1400-1800
- Clutch: Hydraulic, Single plate, dry type diaphragm spring
Specifications
Favourable Coaster Type Mini Bus With 19-33 Seats
|
DIMENSION & WEIGHT |
|||
|
Overall dime |
Length (mm) |
5990 |
|
|
Width (mm) |
2040 |
||
|
Height (mm) |
2600 |
||
|
Wheel base (mm) |
3308 |
||
|
Overhang (mm) (Front / rear) |
1150/1535 |
||
|
Tread (mm) (Front / rear) |
1580/1830 |
||
|
Ground clearance (mm) |
185 |
||
|
Approach& departure angle (°) |
12/21 |
||
|
Curb vehicle weight (kg) |
3200 |
||
|
Gross vehicle weight (kg) |
4710 |
||
|
Seating capacity (person) |
22 |
||
|
Fuel tank (L) |
80 |
||
|
Fuel consumption (L/100km) |
18 |
||
|
Max. gradeability (%) |
30 |
||
|
Min. turning radius (m) |
8 |
||
|
Tires |
Quantity |
6+1 |
|
|
Model |
6.50-16 |
||
|
Air conditioning capacity |
10000kcal/h |
||
|
ENGINE |
|||
|
Model |
CY4102BZLQ |
||
|
Type |
4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged, inter-cooling |
||
|
Bore & stroke (mm) |
102×118 |
||
|
Displacement (cc) |
3856 |
||
|
Max. power (Hp/rpm) |
120 Hp/2800rpm |
||
|
Max. torque (Nm/rpm) |
343/1400 |
||
We offer various kind of bus,includ minibus,city bus,coach,minivan.Our factory is proffesional bus manufacturer has many years producing experiences,the production line lead advanced in domestic.The bus we offer has been popular in Affrica and Middle-east.
Welcome to inquire.
