Zhangjiagang Mars Packing Machinery Co., Ltd.
China Manufacturer with main products: Filling Machine, Beverage Processing Machinery, Bottle Filling Line, Water Treatment Eqipment, Juice/Tea Filling Machine |
4 Cavity Fully Automatic Bottle Blowing Machine
| FOB Price: | 45,000.00 - 50,000.00 USD/Piece |
|---|---|
| Supply Ability: | 170 Piece/Pieces per Year |
| Shipping: | 20 Days |
| Payment Terms: | T/T |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Jiangsu in China |
| Packaging Details: | Wooden case |
Specifications
4 Cavity fully automatic bottle blowing machine:
- BM-A4 Full automatic Bottle Blowing Machine is suitable for producing PET/PE and PP plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.
- Reasonable design, full automatic control, save power and labor.
- Adopt high quality components.
- Feeding system carries the performs by robot automatically.
- Infrared oven heater adopts the quartz lamp to heat the PET tube.
- Fully automatic process with low investment, high efficiency, quick and safe operation, easy for trouble -shooting, maintenance and other benefits.
- We have perfect service after sales.
| Main part: | ||
| Pneumatic part | Valve | FESTO/SMC |
| Cylinder | ||
| Electric part | PLC | LG |
| Operating system | LG | |
| Relay | OMRON | |
| Infrared thermometer | America Raytek | |
| Note | All of the electrical components adopts CE/UL / CCC approved international advanced high-tech product. | |
| Main parameter: | ||
| Model | BM-A4 | |
| Productivity | Depend on bottle design | 3500-3800 Pcs/Hour |
| Product type | Body diameter | ≤100mm |
| Height | ≤310mm | |
| Neck diameter | 18-38mm | |
| Mold | Cavity | 4 cavity |
| Mold thick | 240mm | |
| Mold | 260*240*370mm | |
| Main machine power | Electrical source power | 380V/220V 50/60Hz |
| Rated Power | 49KW | |
| Really use power | 10-15KW | |
| Air source | LP air compressor | 1.6m3 /min 10Kg |
| HP air compressor | 2.0m3 /min 30Kg | |
| Air dryer | 2.0m3 /min 30Kg | |
| Cooling water | Cooling water | 15L/Min |
| Size | L*W*H | 1910*1858*1935mm |
| Weight | 3600Kg | |
| Auxiliary equipment( pre-form unscrambler) | L*W*H | 2000*950*2480mm |
| Weight | 250Kg | |
| Resin available | PET | |
