Steel Track Undercarriage for Drilling Rig

Supply Ability: 1,500 Set(s) per Month
Shipping: 3-20 days
Payment Terms: L/C, T/T

Related products from verified members

Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Packaging Details: pallet or case

Quick Details

  • Brand Name: kemercathy
  • material: steel track undercarriage
  • Condition: 1-100 ton
  • Warranty: 12 months
  • Color: on request
  • Model Number: ST series
  • Type: steel track undercarriage
  • Load capacity: 1-50 ton
  • Track drive: Doosan/Bonfiglioli/Rexroth
  • Travelling speed: 0-10km/hr
  • Dimension: custom built on request
  • Contact: Cathy
  • Tel/whatsapp: 008613486645746
  • Skype: kemercathy

Specifications

Steel track undercarriage manufacter with load capacity 1-50 ton

Steel track undercarriage, Steel track frame, steel track chassis, steel track system, steel crawler undercarriage, steel tracked undercarriage, drilling rig steel track undercarriage, crusher steel track undercarriage, excavator track undercarriage

steel track undercarriage steel crawler undercarriage
Specification of track undercarriage:

1.Load capacity: 500kgs-50,000kgs

2.Walking speed: 0-10km/hr

Drive: dual speed final drive or single speed, Rexroth GFT gearbox

6.Delivery time: 3-20 days

7.Custom built: we can design and manufacture track undercarriage according to your specific dimension requirements.



Our subsidiary company, tracked undercarriage factory, is specialized in the research and development of rubber and steel tracked undercarriage. since the establishment of Bonny, it keeps the whole world in view and blaze steadily new trails. by now, we have developed various tracked undercarriage systems and the load capacity is from 0.5 ton to 50 ton. It has been widely applied in drilling machines (core drill, horizontal directional drilling rig, belt engineering drill, and engineering rig), engineering machines, mining, colliery, agricultural and gardening machines. Meanwhile, we have a lot of experience engineers who can provide you technical support and technical consultancy to meet your needs.

Features:
Adopt steel tracks or.Steel tracks and block rubber.
the track motor can be fixed displacement or variable displacement concealed planetary gearbox and hydraulic motor, such as Nabtesco (Japen), Brevini (Italia). If you need, we can also provide track motor made by our own factory.
the beam is made of Q345B with high loading capacity.
It can also be designed and manufactured on customers' request.
It is widely applied in all kinds of large drilling rig, excavator, paver, Aerial Working Platform and construction engineering machines.
steel track undercarriage crawler undercarriage

MODEL A
Length
B
Center Distance
C
Height
E
Width of track shoe
F
Height of Cross beam
No. of
Roller
Dinamic
Capacity
Static
Capacity
Reduct. Ratio Hydr.
Engine
Cc
Press.  Bar Oil flow
L/min
Torque
Nm to
Engine
Grad. Speed
Km/h
ST-3500 2030 1500 485 300 225 4+4 3500 4000 53.7 23.5/14.7 220 35 4723 65% 2/3.2
ST-6000 2467 1950 549 300-400 240 5+5 6000 7000 53.7 43.7/22.7 220 55 8330 65% 2/3.7
ST-8000 2783 2265 548 400-450 255 8+8 8000 9500 53.7 46.6/27.6 300 82 11700 65% 2.8/4.7
ST-10000 3800 3200 600 400-500 280 9+9 10000 11300 53.7 55.8/32.6 350 100 14800 65% 3/5.1
ST-12000 3282 2575 720 400-600 345 9+9 12000 15000 54 76.6/44.8 350 124 22500 65% 2.9/4.9
ST-15000 3666 2923 753 500-800 360 8+8 15000 18000 53.7 79.5/46.7 350 140 24000 65% 3.2/5.5
ST-20000 4065 3323 786 500-800 375 8+8 20000 25000 48 146.5/95 350 220 38000 65% 3.5/5.4
ST-30000 4530 3730 836 500-800 405 9+9 30000 37000 66.4 173/101 330 260 59000 65% 2.5/4.6
ST-40000 4888 4090 880 500-800 420 10+10 40000 480000 70.1 185/114 350 290 72800 65% 2.3/4.3
steel track undercarriage crawler undercarriage tracked undercarriage track systemsteel track undercarriage crawler undercarriage tracked undercarriage track systemsteel track undercarriage crawler undercarriage tracked undercarriage track systemsteel track undercarriage crawler undercarriage tracked undercarriage track system
